| 1 | | | 1 9960P253086918 253086918 Duplex module |
| 1 | | | 4 9960P189721227 189721227 Line Cord (RJ11) |
| 1 | | | 5 9960P189641841 189641841 Power cord (EU) |
| 1 | | | 8 9960P253235371 253235371 Grip ring tool 1 (**) |
| 1 | | | 9 9960P186205664 186205664 Grip ring DIAM11.5*DIAM4*0.2 THICK |
| 2 | | | 1 9960P253107030 253107030 Left front panel |
| 2 | | | 7 9960P186138735 186138735 Paper guide |
| 3 | | | 2 9960P253125968 253125968 HFFv2 ADF in scanner cable not |
| 4 | | | 3 9960P253058162 253058162 Keypad panel ASM |
| 5 | | | 2 9960P253058183 253058183 LCD front cover ASM HFF-V2 |
| 6 | | | 2 9960P253033053 253033053 Flatbed scanner H&M assy |
| 6 | | | 3 9960P253096005 253096005 HFF V2 Flatbed ground cable |
| 6 | | | 4 9960P189955232 189955232 Flat cable |
| 8 | | | 2 9960P191031847 191031847 Power supply 24V/2A |
| 10 | | | 4 9960P253052798 253052798 Ref card mezz modem |
| 10 | | | 5 9960P253074629 253074629 Mezz modem card |
| 11 | | | 3 9960P253336243 253336243 (SAV) |
| 14 | | | 8 9960P253108540 253108540 Ref interco card |
| 14 | | | 10 9960P253083053 253083053 Ground plate to printer ground plate |
| 15 | | | 2 9960P253093640 253093640 USB host back |
| 15 | | | 3 9960P253083053 253083053 Ground plate to printer ground plate |
| 15 | | | 8 9960P253083029 253083029 HP HFF V2 |
| 15 | | | 9 9960P253066891 253066891 Front panel cable |
| 15 | | | 10 9960P253074596 253074596 USB front cable |
| 15 | | | 11 9960P253066911 253066911 Cable smartcard |
| 15 | | | 12 9960P253108579 253108579 Ref smartcard |
| 16 | | | 1 9960P253110384 253110384 Ref USB board |
| 16 | | | 6 9960P253066903 253066903 Cable keypad |
| 17 | | | 1 9960P253108582 253108582 Ref card DC-DC |
| 17 | | | 3 9960P253083040 253083040 DC-DC 2 wires cables |
| 17 | | | 4 9960P253083032 253083032 DC-DC 5 wires cables |
| 17 | | | 5 9960P253284019 253284019 HDD (160 Gb) |
| 18 | | | 2 9960P253033029 253033029 Input scanner assy |
| 19 | | | 1 9960P253442351 253442351 RIGHT HINGE ASSEMBLY |
| 19 | | | 3 9960P253442343 253442343 LEFT HINGE ASSEMBLY |
| 19 | | | 4 9960P253029294 253029294 Exit tray makalu colored |
| 20 | | | 1 9960P253032811 253032811 ADF cover M&H assy |
| 20 | | | 2 9960P253032788 253032788 Input paperway guide equipped |
| 20 | | | 3 9960P253032725 253032725 ADF M&H assembly |
| 20 | | | 4 9960P189978272 189978272 Photointerrupter optic GP 1S73 SP |
| 21 | | | 7 9960P253032840 253032840 Feeder roller module 2 (*) |
| 22 | | | 8 9960P253032796 253032796 Feeder shoe assy 2 (*) |
| 23 | | | 5 9960P253056431 253056431 CCD Primax box assy |
| 23 | | | 6 9960P253104927 253104927 EQUIPPED |
| 24 | | | 6 9960P186138673 186138673 HFFV2 PRN COVER - FAN MAIN |
| 25 | | | 2 9960P186138777 186138777 ASSY RETARD |
| 25 | | | 5 9960P186138821 186138821 CASSETTE |
| 26 | | | 1 9960P186138850 186138850 CASSETTE |
| 27 | | | 1 9960P186138863 186138863 ASSY J2 |
| 27 | | | 14 9960P186139013 186139013 TONER ASSY |
| 28 | | | 4 9960P186139063 186139063 ASSY 250-J2 |
| 29 | | | 2 9960P186139097 186139097 ASSY ROS |
| 29 | | | 3 9960P186139104 186139104 HFFV2 PRN TNR ZONE - FAN SUB |
| 29 | | | 4 9960P186139117 186139117 ASSY CRU L J2 |
| 29 | | | 5 9960P186139125 186139125 ASSY LOCK1 |
| 29 | | | 6 9960P186139146 186139146 ASSY LOCK3 |
| 29 | | | 7 9960P186139167 186139167 GUIDE CRU |
| 29 | | | 8 9960P186139188 186139188 ASSY FSR |
| 29 | | | 9 9960P186139191 186139191 FSR LH 34PPM |
| 29 | | | 10 9960P186139203 186139203 CRU FSR RH J2 |
| 29 | | | 11 9960P186139224 186139224 ASSY J2 |
| 29 | | | 13 9960P186139245 186139245 TRANSFER (34) |
| 29 | | | 14 9960P186139253 186139253 ASSY ANT P150 |
| 29 | | | 15 9960P186139266 186139266 ASSY ANT |
| 29 | | | 16 9960P186139274 186139274 LINK |
| 30 | | | 1 9960P186139295 186139295 ASSY |
| 31 | | | 1 9960P186139422 186139422 PINCH FU |
| 32 | | | 1 9960P186139456 186139456 MOTOR (J2) |
| 32 | | | 2 9960P186139464 186139464 HOUSING |
| 32 | | | 5 9960P186139498 186139498 PLATE |
| 33 | | | 2 9960P186139526 186139526 HFFV2 PRN ELEC - PS LV 200V J2 |
| 33 | | | 5 9960P186139571 186139571 HFFV2 PRN ELEC - FFC ASSY ESS |
