| Производитель | Cudy |
Beamforming: True
WPS: True
Mesh: Cudy Mesh Main
DHCP: Address Reservation DHCP Client List Server
IPTV/VLAN: Bridge Tag VLAN
IGMP: IGMP Proxy IGMP Snooping
Model Version: LT500 Outdoor 1.0
CPU Details: 580 MHZ Single-Core, MIPS24KEC
Flash/ROM: 16 MB (128 Mbit) NOR
DDR/RAM: 128 MB (1 Gbit) DDR2
5 GHz Wi-Fi Speed: 867 Mbps
2.4 GHz Wi-Fi Speed: 300 Mbps
5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 2× Internal
FEM or PA/LNA: 5 GHz: 2× Internal 2.4 GHz: 2× Internal
Range Performance: Max: 170 m (558 ft)Park: 150 m (492 ft)Street: 50 m (164 ft)Woods: 30 m (98 ft)
Wall Performance: NA
Ethernet Notes: Accepts PoE powering
LED: System Internet LAN Wi-Fi Cellular Signal Strength
Physical Buttons: Reset Button
Power Input: PoE via Ethernet Port
Power Methods: Passive PoE
Power Adapter: Input: 100 ~ 240 V, 50/60 Hz ACOutput: 24V 0.5A DC
Max Power Consumption (W): 10W
Environment: Operating Temperature: -20 ℃ ~ 60 ℃ (-4 ℉ ~140 ℉) Extend Operating Temperature with Industrial Grade SIM Card: -40 ℃ ~ 65 ℃ (-40 ℉ ~ 149 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 0% ~ 100% non-condensing Storage Humidity: 5% ~ 90% non-condensing
Certifications: FCC, CE
Installation: Wall-mount Pole-mount
Dimension: Device Body: 240×100×53.7 mm9.45×3.94×2.11 inchesEach Antenna: 197.5×21.6×15.5 mm7.78×0.85×0.61 inches
Product Weight: 420 g (14.82 oz.)
Package Content: LT500 Outdoor Detachable Antennas PoE Adapter Power Cord Mounting Kit Ethernet Cable Installation Guide
Retail Package Weight: EU: 785 g (27.69 oz.) US: 782 g (27.58 oz.)
Retail Package Dimension: 324×107×86 mm12.76×4.21×3.39 inches
Units per Carton: 20
Carton Dimension: 46×33.7×45 cm18.11×13.27×17.72 inches
Carton Gross Weight: EU: 16.6 kg (36.6 lbs) US: 16.5 kg (36.38 lbs)
Carton Net Weight: EU: 15.7 kg (34.61 lbs) US: 15.6 kg (34.39 lbs)
Wi-Fi Standards: Wi-Fi 5
Max Wi-Fi Modulation: 256-QAM
Wi-Fi Efficiency: MU-MIMO
Max Capacity: 128
Recommended Client Upper Limit: 50
Max Wi-Fi Channel Width: 80 MHz
Wi-Fi Security: WPA/WPA2/WPA3
Guest Network: 2.4 GHz, 5 GHz
Operation Modes: Cellular Router Wi-Fi Router WISP
Mesh Backhaul: Wireless Backhaul Wired Backhaul
WAN Mode: DHCP Static IP PPPOE
QoS: Per-User Rate Limiting
IP Versions: IPv4/IPv6
IPv6 Protocols: Relay Dynamic (SLAAC/DHCPv6) Static (Fixed IP) Passthrough 464XLAT MAP-E DS-Lite
TTL Customization: Extend Spoof Custom
Forwarding: Port Forwarding Port Triggering UPnP DMZ
Firewall: SPI Firewall DoS Protection Block PING
Application Layer Gateway: IPSec Passthrough L2TP Passthrough PPTP Passthrough FTP Passthrough TFTP Passthrough H323 Passthrough SIP Passthrough RTSP Passthrough
VPN Server: WireGuard OpenVPN IPsec Zerotier PPTP L2TP
VPN Client: WireGuard OpenVPN IPsec Zerotier PPTP L2TP
DNS Options: DNS over TLS Manual DNS Rebind Protection Override Clients' DNS
DNS over TLS Providers: Cloudflare Google Quad9 Custom
Wake on LAN: True
Online Detection: True
Parental Controls: Profiles Settings Offline Time Online Time Pause the Internet Web Filter
All Devices Management: Wi-Fi Time Schedule MAC Filter IP/MAC Binding
Per-Devices Management: Internet On/Off VPN On/Off Online Time Schedule Device Rename
Content Management: Domain Filter IP Filter
Local Control Method: Config Web Page App Control
Remote Control Method: Config Page via HTTPS App Control TR069/TR098/TR111/TR143/TR181
Firmware Upgrade: Local Update App (Over the Air) Online Update
Reliability: Timed Reboot Backup and Restore
Diagnostic Tools: Diagnosis Ping Traceroute NSLookup System Log
Languages: English Bengali Catalan Czech German Greek Spanish French Hebrew Croatian Hungarian Italian Japanese Khmer Korean Dutch Norwegian Polish Portuguese Romanian Russian Slovak Swedish Thai Turkish Ukrainian Vietnamese Simplified Chinese Trad
