| 1 | 2N1641 запросить цену → | | PLATEN COVER ASSEMBLY |
| 2 | | | - PLATEN COVER (P/O PL 1.1 item |
| 3 | | | - PLATEN CUSHION (P/O PL 1.1 |
| 4 | 29N194 запросить цену → | | UPPER PIVOT |
| 5 | 2N1642 запросить цену → | | SCAN COVER ASSEMBLY |
| 6 | | | - SCAN COVER (P/O PL 1.1 item 5) |
| 7 | | | - LEFT REGISTRATION EDGE |
| 8 | | | - TOP REGISTRATION EDGE |
| 9 | 62N172 запросить цену → | | PLATEN GLASS ASSEMBLY ( |
| 10 | | | - PAPER SHADING LABEL (P/O PL |
| 11 | | | - PLATEN GLASS (P/O PL 1.1 item |
| 1 | | | - IDLE BRACKET ASSEMBLY (NOT |
| 2 | | | - IDLE PULLEY (NOT SPARED) |
| 3 | | | - IDLE PULLEY SHAFT (NOT |
| 4 | | | - PULLEY HOLDER (NOT SPARED) |
| 5 | | | - SPRING (NOT SPARED) |
| 6 | | | - IDLE BRACKET (NOT SPARED) |
| 7 | 130N922 запросить цену → | | CONTACT IMAGE SENSOR ( REP |
| 8 | 9N1083 запросить цену → | | SPRING |
| 9 | | | - CARRIAGE (NOT SPARED) |
| 10 | | | - CLAMP BEARING (NOT SPARED) |
| 11 | | | - CLAMP BEARING |
| 12 | | | - CARRIAGE SHAFT (NOT |
| 13 | 2N1639 запросить цену → | | SCAN COVER (L) |
| 14 | | | - SCAN LOCK (NOT SPARED) |
| 15 | | | - CAP (NOT SPARED) |
| 16 | 64N28 запросить цену → | | SCANNER DRIVE BELT ( REP 2.2) |
| 17 | 2N1645 запросить цену → | | SCAN MOTOR COVER |
| 18 | 117N1278 запросить цену → | | RIBBON CABLE |
| 19 | | | - LOWER PIVOT (NOT SPARED) |
| 20 | 17N173 запросить цену → | | RUBBER FOOT |
| 21 | | | - SLIDER (F) (NOT SPARED) |
| 22 | | | - SLIDER (R) (NOT SPARED) |
| 23 | 830E28530 запросить цену → | | STOP BRACKET |
| 1 | 30N445 запросить цену → | | SCAN MOTOR ASSEMBLY ( REP |
| 2 | | | - MOTOR BRACKET (P/O PL 1.3 |
| 3 | 127N1027 запросить цену → | | SCAN MOTOR (MOT 1) |
| 4 | | | - IDLER GEAR (P/O PL 1.3 item 1) |
| 5 | | | - REDUCTION GEAR (P/O PL 1.3 |
| 6 | | | - TIMING PULLEY (P/O PL 1.3 item |
| 7 | | | - PULLEY FLANGE (P/O PL 1.3 |
| 8 | | | - E-RING (P/O PL 1.3 item 1) |
| 1 | 2N1640 запросить цену → | | MAIN COVER ASSEMBLY ( REP |
| 2 | | | - MAIN COVER (P/O PL 1.4 item 1) |
| 3 | | | - PLATE LOCK (P/O PL 1.4 item 1) |
| 4 | 30N444 запросить цену → | | SCANNER SUPPORT BRACKET |
| 5 | | | - INTERLOCK SENSOR (P/O PL |
| 6 | | | - REAR COVER (NOT SPARED) |
| 1 | 2N1643 запросить цену → | | CONTROL PANEL ASSEMBLY ( |
| 2 | | | - FRONT COVER (P/O PL 1.5 item |
| 3 | | | - PLATE (P/O PL 1.5 item 1) |
| 4 | | | - PANEL (P/O PL 1.5 item 1) |
| 5 | | | - TOP KEY (L) (P/O PL 1.5 item 1) |
| 6 | | | - TOP KEY (R) (P/O PL 1.5 item 1) |
| 7 | | | - START KEY (P/O PL 1.5 item 1) |
| 8 | | | - STOP KEY (P/O PL 1.5 item 1) |
| 9 | | | - SPACER |
| 10 | 140N5327 запросить цену → | | CONTROL PANEL PWB ( REP 5.2) |
| 11 | 152N1687 запросить цену → | | CONTROL PANEL HARNESS |
| 1 | 41N201 запросить цену → | | PAPER FEEDER ASSEMBLY ( |
| 2 | | | - SIDE PAPER GUIDE (P/O PL 1.6 |
| 3 | | | - TENSION PLATE (P/O PL 1.6 item |
| 4 | | | - PAPER PRESSURE PLATE (P/O |
| 5 | | | - LATCH GUIDE (P/O PL 1.6 item 1) |
| 6 | | | - DAMPER LEVER (P/O PL 1.6 item |
| 7 | | | - ENVELOPE GUIDE (P/O PL 1.6 |
| 8 | | | - PAD (P/O PL 1.6 item 1) |
| 9 | | | - MANUAL GUIDE (L) (P/O PL 1.6 |
| 10 | | | - MANUAL GUIDE (R) (P/O PL 1.6 |
| 11 | | | - MANUAL PLATE (P/O PL 1.6 item |
| 12 | | | - FILM GUIDE (P/O PL 1.6 item 1) |
| 13 | | | - SPRING (P/O PL 1.6 item 1) |
| 14 | | | - CLUTCH HUB (P/O PL 1.6 item 1) |
| 15 | | | - CLUTCH SPRING (P/O PL 1.6 |
| 16 | | | - PAPER FEED CLUTCH (P/O PL |
| 17 | | | - SUPPORT GUIDE (P/O PL 1.6 |
| 18 | | | - CLUTCH GEAR (P/O PL 1.6 item |
| 19 | | | - CLUTCH PAWL (P/O PL 1.6 item |
| 1 | | | - EXTENSION GUIDE (P/O PL 1.6 |
| 2 | | | - PAPER FEEDER GUIDE (P/O PL |
| 3 | | | - PICK UP CAM (P/O PL 1.6 item 1) |
| 4 | | | - PAPER FEEDER FINGER (P/O PL |
| 5 | | | - FINGER SPRING (P/O PL 1.6 item |
| 6 | | | - FINGER LEVER SPRING (P/O PL |
| 7 | | | - FINGER LEVER (P/O PL 1.6 item |
| 8 | | | - FINGER BRACKET (P/O PL 1.6 |
| 9 | | | - PICK UP SHAFT (P/O PL 1.6 item |
| 10 | | | - IDLE ROLLER (P/O PL 1.6 item 1) |
| 11 | | | - FEED ROLLER (P/O PL 1.6 item |
| 12 | | | - RETURN LEVER (P/O PL 1.6 item |
| 13 | | | - LEVER BUSHING (P/O PL 1.6 |
| 14 | | | - RETURN LEVER SPRING (P/O |
| 15 | 60K1530 запросить цену → | | CARTRIDGE STORAGE |
| 1 | 2N1644 запросить цену → | | CARRIAGE ASSEMBLY |
| 2 | | | - CARRIAGE DRIVE BELT (P/O PL |
| 3 | | | - PRINT HEAD CRADLE (P/O PL |
| 4 | 140N5324 запросить цену → | | CARRIAGE PWB |
| 5 | | | - LATCH HEAD SPRING (P/O PL |
| 6 | | | - RUBBER CAP (P/O PL 1.8 item 1) |
| 7 | | | - CARRIER FRAME (P/O PL 1.8 |
| 8 | | | - CONTACT INSULATOR (P/O PL |
| 9 | | | - BEARING CLAMP (P/O PL 1.8 |
| 10 | | | - BEARING CLAMP (P/O PL 1.8 |
| 11 | | | - ENCODER SENSOR (Q1) (P/O PL |
| 12 | | | - IDLE PULLEY (P/O PL 1.8 item |
| 13 | | | - IDLE PULLEY SHAFT (P/O PL 1.8 |
| 14 | | | - PULLEY HOLDER (P/O PL 1.8 |
| 15 | | | - PULLEY (P/O PL 1.8 item 25) |
| 16 | | | - PULLEY SPRING (P/O PL 1.8 item |
| 17 | 9N1070 запросить цену → | | CARRIAGE SHAFT SPRING |
| 18 | 6N931 запросить цену → | | CARRIAGE SHAFT |
| 19 | 146N96 запросить цену → | | ENCODER TAPE ( REP 8.2) |
| 20 | | | - ENCODER SPRING |
| 21 | | | - MAIN FRAME |
| 22 | | | - RIGHT FEED BEARING |
| 23 | 127N1011 запросить цену → | | CARRIAGE MOTOR (MOT 2) ( |
| 24 | | | - CABLE CLAMP |
| 25 | | | - IDLER PULLEY ASSEMBLY (NOT |
| 26 | 152N1688 запросить цену → | | HARNESS |
| 1 | 30N433 запросить цену → | | PAPER FEED MOTOR BRACKET |
| 2 | 127N1026 запросить цену → | | PAPER FEED MOTOR (MOT 3) |
| 3 | | | - LEFT BRACKET (P/O PL 1.9 item |
| 4 | | | - LEFT IDLE GEAR (P/O PL 1.9 item |
| 5 | | | - GEAR 10/48 (P/O PL 1.9 item 1) |
| 6 | | | - GEAR 39/51 (P/O PL 1.9 item 1) |
| 7 | | | - GEAR 25/50 (P/O PL 1.9 item 1) |
| 8 | 13N401 запросить цену → | | LEFT FEED BEARING |
| 9 | 22N1040 запросить цену → | | ROLLER FRICTION HOLDER |
| 10 | | | - FRICTION SPRING (P/O PL 1.9 |
| 11 | | | - FEED ACTUATOR (P/O PL 1.9 |
| 12 | | | - ACTUATOR SPRING (P/O PL 1.9 |
| 13 | | | - ROLLER HOLDER (P/O PL 1.9 |
| 14 | | | - FRICTION ROLLER HOLDER (P/O |
| 15 | | | - FRICTION ROLLER (P/O PL 1.9 |
| 16 | | | - DEFLECTOR (P/O PL 1.9 item 9) |
| 17 | 22N1039 запросить цену → | | RIBBON CABLE HOLDER |
| 18 | 64N27 запросить цену → | | PAPER FEED SENSOR (Q2) |
| 19 | | | - RIBBON CABLE HOLDER (P/O |
| 1 | 1N304 запросить цену → | | CARRIAGE HOME ASSEMBLY ( |
| 2 | | | - RUBBER CAP HEAD (P/O PL 1.10 |
| 3 | | | - CAP HOLDER (P/O PL 1.10 item |
| 4 | | | - SPRING (P/O PL 1.10 item 1) |
| 5 | | | - LATCH LEVER (P/O PL 1.10 item |
| 6 | | | - RUBBER WIPE HEAD (P/O PL |
| 7 | | | - CLEANING DRUM (P/O PL 1.10 |
| 8 | | | - MAINTENANCE STATION (P/O PL |
| 9 | | | - LATCH SPRING (P/O PL 1.10 item |
| 10 | | | - MAINTENANCE STATION BASE |
| 11 | 1N303 запросить цену → | | BASE FRAME ASSEMBLY ( REP |
| 12 | | | - WHEEL HUB (P/O PL 1.10 item |
| 13 | | | - STAR WHEEL (P/O PL 1.10 item |
| 14 | | | - WHEEL HOLDER (P/O PL 1.10 |
| 15 | | | - EXIT ROLLER (P/O PL 1.10 item |
| 16 | | | - EXIT ROLLER SHAFT (P/O PL |
| 17 | | | - BASE FRAME (P/O PL 1.10 item |
| 18 | | | - WHEEL SPRING (P/O PL 1.10 |
| 19 | | | - EXIT BELT (P/O PL 1.10 item 11) |
| 20 | | | - PINCH ROLLER (P/O PL 1.10 item |
| 21 | 22N1041 запросить цену → | | FEED ROLLER ASSEMBLY ( REP |
| 22 | | | - EXIT PULLEY (P/O PL 1.10 item |
| 23 | | | - FEED ROLLER (P/O PL 1.10 item |
| 24 | | | - FEED ROLLER GEAR (P/O PL |
| 1 | | | - BASE COVER ASSEMBLY |
| 2 | | | - BASE COVER (P/O PL 1.11 item |
| 3 | | | - DUMMY BASE (P/O PL 1.11 item |
| 4 | | | - LONG STACKER (P/O PL 1.11 |
| 5 | | | - SHORT STACKER (P/O PL 1.11 |
| 6 | | | - SHIELD PLATE (M) (P/O PL 1.11 |
| 7 | 19N443 запросить цену → | | INK FELT |
| 8 | 19N442 запросить цену → | | LOWER FELT |
| 9 | 17N173 запросить цену → | | RUBBER FOOT |
| 10 | 140N5326 запросить цену → | | MAIN PWB ( ) |
| 11 | 140N5325 запросить цену → | | DRIVER PWB ( ) |
| 12 | | | - SHIELD PLATE (C) (NOT |
| 13 | 105N1275 запросить цену → | | LVPS PWB ( ) |
| 14 | | | - RIBBON CABLE (FFC30P) (NOT |
| 15 | 152N1688 запросить цену → | | HARNESS |
| 16 | | | - GROUND WIRE (NOT SPARED) |
| 17 | 117E13660 запросить цену → | | US POWER CORD |
| 18 | 117N1313 запросить цену → | | USB 6FT CABLE |
| 19 | 108N430 запросить цену → | | FUSE (24OV .2A) |
