| 1 | 2N1566 запросить цену → | | FRONT DOOR (XE) |
| 2 | | | - OUTPUT TRAY (USO/XCL) (REP |
| 3 | | | - SCREW (3X8) |
| 4 | 50N259 запросить цену → | | TRAY EXTENSION (XE) |
| 5 | | | - SCREW (4X12) |
| 6 | | | - CONTROL CONSOLE (REP 14.5) |
| 7 | 152N1630 запросить цену → | | CONTROL CONSOLE HARNESS |
| 8 | | | - HARNESS |
| 9 | | | - SCREW (3X8) |
| 10 | | | - TOP LEFT COVER |
| 11 | | | - INSTRUCTION LABEL |
| 12 | 90N138 запросить цену → | | DOCUMENT GLASS ASSEMBLY |
| 13 | | | - REGISTRATION GUIDE |
| 14 | 1N299 запросить цену → | | CALIBRATION STRIP |
| 15 | | | - ADHESIVE STRIP |
| 16 | | | - DOCUMENT GLASS |
| 17 | 2N1591 запросить цену → | | TOP RIGHT COVER (USO/XCL |
| 18 | | | - REAR COVER |
| 19 | | | - CAUTION LABEL |
| 20 | | | - LABEL |
| 21 | | | - SERVICE LABEL |
| 22 | | | - FAN GASKET |
| 23 | 53N142 запросить цену → | | OZONE FILTER |
| 24 | 1N300 запросить цену → | | DOCUMENT GLASS EDGE |
| 25 | | | - SDF WINDOW |
| 26 | | | - SDF GLASS CUSHION |
| 27 | | | - SMALL REAR COVER |
| 28 | 38N274 запросить цену → | | REAR SHIELD(XD103F/105F |
| 29 | 38N275 запросить цену → | | FRONT SHIELD |
| 30 | | | - CUSHION (XD155DF) |
| 31 | | | - TAPE (XD155DF) |
| 1 | | | - REAR PIVOT ATTACHMENT |
| 2 | | | - DOCUMENT COVER |
| 3 | | | - DOCUMENT COVER CUSHION |
| 4 | | | - DOCUMENT ORGANIZER |
| 5 | 2N1534 запросить цену → | | DOCUMENT COVER ASSEMBLY |
| 6 | 2N1526 запросить цену → | | DOCUMENT COVER ASSEMBLY |
| 5-8 | | | WorkCentre XD SERIES |
| 1 | 53N162 запросить цену → | | CONTROL BUTTON COVER |
| 2 | | | - CONTROL CONSOLE COVER |
| 3 | 3N673 запросить цену → | | START PRINT BUTTON |
| 4 | | | - CLEAR/STOP BUTTON |
| 5 | | | - FUNCTION BUTTON (R) |
| 6 | | | - FUNCTION BUTTON (L) |
| 7 | | | - BOOK MODE SELECT BUTTON |
| 8 | 140N5223 запросить цену → | | CONTROL CONSOLE PWB |
| 9 | | | - GROUNDING SPRING |
| 10 | | | - SCREW (3X8) |
| 11 | 2N1593 запросить цену → | | CONTROL CONSOLE |
| 1 | 2N1730 запросить цену → | | SIDE DOOR (USO/XCL) |
| 2 | 3N668 запросить цену → | | SIDE DOOR LATCH |
| 3 | 9N978 запросить цену → | | LATCH SPRING |
| 4 | | | - HINGE GUIDE |
| 5 | | | - GROUNDING PLATE |
| 6 | | | - GROUNDING SPRING |
| 7 | | | - SCREW (3X6) |
| 8 | | | - SCREW (3X6) |
| 9 | | | - INNER PAPER GUIDE |
| 10 | | | - SCREW (3X10) |
| 11 | 9N964 запросить цену → | | PRESSURE SPRING |
| 12 | 152N1635 запросить цену → | | GROUND WIRE |
| 13 | | | - GROUNDING SPRING |
| 14 | 9N962 запросить цену → | | PRESSURE SPRING |
| 15 | | | - SHAFT |
| 16 | | | - E-RING |
| 17 | 22E22060 запросить цену → | | UPPER ROLLER |
| 18 | 19N415 запросить цену → | | TRANSFER/DETACK COROTRON |
| 19 | | | - SCREW (3X8) (XD155DF) |
| 20 | 7N750 запросить цену → | | DUPLEX DRIVE GEAR (XD155DF) |
| 21 | 7N751 запросить цену → | | DUPLEX DRIVE GEAR A |
| 22 | 22N1002 запросить цену → | | DUPLEX DRIVE ROLLER |
| 23 | 9N1027 запросить цену → | | DUPLEX PRESSURE SPRING |
| 5-10 | | | WorkCentre XD SERIES |
| 1 | 22N926 запросить цену → | | EXIT ROLLER (REP 8.9) |
| 2 | | | - BEARING |
| 3 | 22N925 запросить цену → | | LOWER TRANSPORT ROLLER |
| 4 | | | - PULLEY (22T) |
| 5 | 23N596 запросить цену → | | EXIT DRIVE BELT |
| 6 | | | - CABLE TIE |
| 7 | | | - COUPLING |
| 8 | | | - SPRING |
| 9 | 127N972 запросить цену → | | TONER MOTOR (MOT 4) (REP |
| 10 | | | - SCREW (3X10) |
| 11 | | | - SCREW (3X30) |
| 12 | 127N971 запросить цену → | | VENTILATION FAN (MOT 3) (REP |
| 13 | | | - TRANSFER COROTRON |
| 14 | | | - BIAS CONTROL PLATE |
| 15 | | | - SCREW (3X6) |
| 16 | | | - TRANSFER COROTRON PLATE |
| 17 | | | - SCREW (3X6) |
| 18 | | | - BIAS CONTROL HARNESS |
| 19 | | | - TRANSFER COROTRON |
| 20 | | | - MANUAL EXIT DRIVE BELT (REP |
| 21 | | | - CENTER FRAME |
| 22 | | | - MANUAL EXIT KNOB |
| 23 | | | - FUSER JAM SENSOR HARNESS |
| 25 | | | - HARNESS GUIDE |
| 26 | | | - GUIDE PIN |
| 27 | | | - DVS HARNESS |
| 28 | | | - SCREW (3X6) |
| 29 | | | - SCREW (3X8) |
| 30 | | | - SCREW (4X12) |
| 31 | | | - DUPLEX MOTOR MOUNTING |
| 32 | | | - DUPLEX SPACER (XD155DF |
| 33 | | | - SCREW (3X10) (XD155DF) |
| 34 | | | - SCREW (3X6) (XD155DF) |
| 35 | 127N996 запросить цену → | | EXIT DRIVE MOTOR (MOT5) |
| 36 | | | - SHIELD (XD155DF) |
| 1 | | | - MAIN DRIVE ASSEMBLY (REP |
| 2 | 127N969 запросить цену → | | MAIN DRIVE MOTOR (MOT 1) |
| 3 | | | - SPRING |
| 4 | | | - GEAR |
| 5 | | | - PULLEY |
| 6 | | | - GEAR (28T) |
| 7 | | | - GEAR (46/16T) |
| 8 | | | - GEAR (30/15T) |
| 9 | | | - DRIVE GEAR ASSEMBLY |
| 10 | | | - GEAR (37/15T) |
| 11 | | | - GEAR (68/26T) |
| 12 | | | - COUPLING GEAR (34T) |
| 13 | | | - RATCHET GEAR (21T) |
| 14 | | | - RATCHET GEAR (28T) |
| 15 | | | - SPRING |
| 16 | | | - GEAR (55/19T) |
| 17 | | | - GEAR (33/20/15T) |
| 18 | | | - GEAR (20T) |
| 19 | | | - GEAR (31/17T) |
| 20 | | | - MAIN DRIVE BRACKET |
| 21 | | | - SCREW (3X4) |
| 22 | 121N401 запросить цену → | | SOLENOID REGISTRATION ROLL |
| 23 | | | - SPRING |
| 24 | | | - PAWL |
| 25 | 121N400 запросить цену → | | SOLENOID PAPER FEED (SOL 1) |
| 26 | | | - PAWL |
| 27 | | | - SCREW (4X6) |
| 28 | 152N1633 запросить цену → | | MAIN MOTOR HARNESS |
| 5-12 | | | WorkCentre XD SERIES |
| 1 | | | - SCAN CABLE |
| 2 | | | - HALF RATE CARRIAGE |
| 3 | 62N139 запросить цену → | | EXPOSURE LAMP CARRIAGE |
| 4 | | | - CABLE CLAMP |
| 5 | | | - SCREW (3X5) |
| 6 | | | - EXPOSURE LAMP HARNESS |
| 7 | | | - SCREW |
| 8 | | | - PULLEY STUD PLATE |
| 9 | | | - PULLEY |
| 10 | | | - PULLEY |
| 11 | | | - E-RING |
| 12 | | | - OPTICS FRAME |
| 13 | | | - SCREW (3X8) |
| 14 | | | - SCAN RAIL (REAR) |
| 15 | | | - SCAN RAIL (FRONT) |
| 16 | | | - SCREW |
| 17 | | | - E-RING |
| 18 | 7N694 запросить цену → | | SCAN DRIVE GEAR/PULLEY |
| 19 | | | - MOTOR TENSION SPRING |
| 20 | 127K30270 запросить цену → | | SCAN DRIVE MOTOR (MOT 2) |
| 21 | | | - SCAN DRIVE MOTOR MOUNTING |
| 22 | | | - E-RING |
| 23 | | | - BEARING |
| 24 | | | - SPRING PIN (3MM) |
| 25 | | | - SCAN DRIVE PULLEY |
| 26 | | | - SCAN DRIVE BELT |
| 27 | | | - SCREW (3X4) |
| 28 | | | - SCAN CABLE HUB |
| 29 | | | - SCREW (4X6) |
| 30 | | | - SCAN CABLE DRIVE SHAFT |
| 31 | | | - BEARING |
| 32 | | | - WASHER |
| 33 | | | - OPTICS FRAME ASSEMBLY (REP |
| 1 | | | - SCREW (3X8) |
| 2 | | | - LENS COVER |
| 3 | | | - EXPOSURE LAMP HARNESS |
| 4 | | | - HARNESS GUIDE |
| 5 | 152N1632 запросить цену → | | CCD HARNESS |
| 6 | | | - SCREW |
| 7 | 62N141 запросить цену → | | LENS/CCD MODULE (REP 6.5) |
| 8 | | | - SCREW (3X8) |
| 9 | 140N5112 запросить цену → | | SCAN HOME SENSOR (Q5) |
| 10 | | | - DOCUMENT GLASS CUSHION |
| 11 | | | - RIBBON GUIDE |
| 12 | | | - PROTECTOR SHEET |
| 13 | | | - DISCHARGE BRUSH |
| 14 | | | - OPTICS FRAME GUIDE |
| 15 | | | - UPPER DUPLEX PAPER GUIDE |
| 16 | | | - CAUTION LABEL |
| 17 | | | - CCD HARNESS COVER |
| 18 | | | - CCD PWB COVER |
| 19 | | | - FERRITE HOLDER |
| 20 | | | - LOWER SHEET |
| 21 | | | - SCREW (4X12) |
| 22 | | | - FERRITE |
| 23 | | | - CUSHION |
| 24 | | | - SDF LEFT HINGE GUIDE |
| 25 | | | - SDF RIGHT HINGE GUIDE |
| 26 | | | - SCREW (3X8) (XD120F) |
| 27 | | | - WIRE BAND (XD120F) |
| 28 | | | - BAND (PLT1M) (XD120F) |
| 29 | | | - WIRE HOLDER (LWS-1M) |
| 30 | | | - CUSHION (XD155DF) |
| 31 | | | - CRIP HOLDER (XD155DF) |
| 5-14 | | | WorkCentre XD SERIES |
| 1 | | | - SCREW (3X6) |
| 2 | | | - LASER HARNESS COVER |
| 3 | 152N1718 запросить цену → | | LASER HARNESS |
| 4 | | | - TIE WRAP |
| 5 | 62N142 запросить цену → | | LASER MODULE |
| 6 | | | - SPRING |
| 7 | | | - SCREW |
| 8 | | | - SPIRAL WRAP (XD155DF) |
| 1 | | | - LIGHT SHIELD |
| 2 | | | - HALF RATE CARRIAGE |
| 3 | | | - SCREW (4X6) |
| 4 | | | - PULLEY |
| 5 | | | - GUIDE |
| 6 | | | - SCREW (4X6) |
| 7 | 10N64 запросить цену → | | SLIDE BUTTON |
| 8 | | | - SCREW |
| 9 | | | - PULLEY BRACKET (REAR) |
| 10 | | | - CUSHION (REAR) |
| 11 | 19E26730 запросить цену → | | MIRROR CLIP |
| 12 | 62N140 запросить цену → | | MIRROR |
| 13 | | | - PULLEY BRACKET (FRONT) |
| 14 | | | - CUSHION (FRONT) |
| 15 | | | - HALF RATE CARRIAGE |
| 5-16 | | | WorkCentre XD SERIES |
| 1 | | | - PAPER PRESSURE PLATE |
| 2 | | | - RETARD PAD |
| 3 | 120E10520 запросить цену → | | PRESSURE PLATE LOCK |
| 4 | 3E26060 запросить цену → | | PAPER SIZE GUIDE |
| 5 | | | - FRONT PAPER GUIDE |
| 6 | | | - FRONT PAPER SNUBBER |
| 7 | | | - E-RING |
| 8 | | | - LABEL |
| 9 | | | - SCREW (3X8) |
| 10 | | | - WASHER |
| 11 | | | - GEAR |
| 12 | | | - LOAD LABEL |
| 13 | | | - REAR PAPER GUIDE |
| 14 | | | - REAR PAPER SNUBBER |
| 15 | 809E24950 запросить цену → | | LIFT SPRING |
| 16 | 9E63280 запросить цену → | | TRAY SPRING |
| 17 | | | - SPRING |
| 18 | | | - PLATE RELEASE |
| 19 | | | - TRAY FRAME |
| 20 | | | - LABEL |
| 21 | 50N233 запросить цену → | | 250 SHEET PAPER TRAY |
| 1 | 140N5109 запросить цену → | | TRAY 1 PAPER FEED SENSOR |
| 2 | | | - SENSOR ACTUATOR |
| 3 | | | - ACTUATOR SPRING |
| 4 | | | - SCREW (3X10) |
| 5 | | | - UPPER FRONT PAPER GUIDE |
| 6 | | | - E-RING |
| 7 | 22N929 запросить цену → | | LOWER REGISTRATION ROLLER |
| 8 | | | - BEARING |
| 9 | | | - CLUTCH GEAR (26T) |
| 10 | 5E9640 запросить цену → | | CLUTCH SLEEVE |
| 11 | | | - CLUTCH SPRING |
| 12 | | | - SPRING PIN |
| 13 | | | - CLUTCH BOSS |
| 14 | | | - E-RING |
| 15 | | | - CLUTCH BOSS |
| 16 | | | - CLUTCH SPRING |
| 17 | 16N174 запросить цену → | | CLUTCH SLEEVE |
| 18 | | | - CLUTCH GEAR (29T) |
| 19 | | | - BEARING |
| 20 | | | - PAPER FEED ROLLER (REP 8.6) |
| 21 | | | - GEAR (33T) |
| 22 | | | - GEAR (21/29T) |
| 23 | | | - GEAR (30T) |
| 24 | | | - GEAR SUPPORT BRACKET |
| 25 | | | - GROUNDING PLATE |
| 26 | 110N817 запросить цену → | | TRAY DETECT SWITCH (S2) |
| 27 | 152N1638 запросить цену → | | TRAY DETECT SWITCH |
| 28 | | | - BASE FRAME |
| 29 | | | - RETARD PAD |
| 30 | | | - RETARD ARM |
| 31 | | | - LIFT SPRING |
| 32 | | | - RETARD SUPPORT PLATE |
| 33 | | | - SPRING (XD100/102) |
| 34 | | | - PAPER GUIDE |
| 35 | | | - SCREW (4X12) |
| 36 | 38E13480 запросить цену → | | RETARD PAD (XD104) |
| 37 | | | - SCREW (3X8) |
| 38 | | | - SENSOR COVER |
| 39 | | | - D-RST HARNESS |
| 40 | | | - SCREW (3X12) |
| 41 | | | - FRONT LEVER SPRING |
| 42 | 3N764 запросить цену → | | FRONT LEVER PLATE |
| 43 | | | - WASHER |
| 44 | | | - GUIDE (XD155DF) |
| 45 | | | - SCREW (4X12) (XD120F) |
| 46 | | | - FIXING PLATE (XD120F) |
| 47 | | | - JOINT GEAR (XD120F) |
| 48 | | | - E-RING (XD120F) |
| 5-18 | | | WorkCentre XD SERIES |
| 1 | 22N933 запросить цену → | | SINGLE BYPASS ASSEMBLY |
| 2 | | | - GROUND WIRE |
| 3 | | | - TIE WRAP |
| 4 | | | - SCREW (3X6) |
| 5 | | | - PAPER FEED BRACKET |
| 6 | | | - GEAR (27T) |
| 7 | | | - E-RING |
| 8 | | | - SCREW 3X8) |
| 9 | | | - GEAR (16T) |
| 10 | | | - SPRING PIN |
| 11 | | | - BUSHING |
| 12 | 22N932 запросить цену → | | TRANSPORT ROLLER (REP 8.7) |
| 13 | | | - BYPASS FRAME |
| 14 | | | - GROUNDING SPRING |
| 15 | | | - SCREW (3X6) |
| 16 | | | - ACTUATOR SPRING |
| 17 | | | - ACTUATOR |
| 18 | | | - SPRING |
| 19 | 140N5106 запросить цену → | | SINGLE SHEET BYPASS FEED |
| 20 | | | - DUPLEX UPPER GUIDE |
| 21 | | | - SINGLE BYPASS GUIDE (R) |
| 22 | | | - SINGLE BYPASS GUIDE (F) |
| 23 | | | - SCREW (3X6) |
| 24 | 22E22060 запросить цену → | | BYPASS ROLL |
| 25 | | | - SINGLE BYPASS FRAME |
| 26 | | | - SPRING |
| 27 | | | - PAPER FEED GEAR |
| 28 | | | - SCREW (3X6) |
| 29 | | | - GROUNDING SPRING |
| 30 | | | - SCREW (3X6) |
| 31 | | | - GROUNDING SPRING |
| 32 | | | - SCREW (4X12) |
| 33 | 22N930 запросить цену → | | SINGLE BYPASS UPPER |
| 1 | 42E1430 запросить цену → | | COROTRON CLEANER |
| 2 | | | - SCREW |
| 3 | | | - UPPER COVER |
| 4 | 110N783 запросить цену → | | SIDE DOOR INTERLOCK SWITCH |
| 5 | | | - SCREW (2X16) |
| 6 | | | - SWITCH ACTUATOR |
| 7 | | | - CAUTION LABEL (XE) |
| 5-20 | | | WorkCentre XD SERIES |
| 1 | 42E1430 запросить цену → | | COROTRON CLEANER |
| 2 | | | - SCREW |
| 3 | | | - UPPER COVER |
| 4 | 110N783 запросить цену → | | SIDE DOOR INTERLOCK SWITCH |
| 5 | | | - CAUTION LABEL (XE) |
| 6 | | | - SWITCH ACTUATOR |
| 1 | 5E10560 запросить цену → | | FEED ROLL (REP 8.15) |
| 2 | | | - E-RING |
| 3 | | | - GEAR (20T) |
| 4 | | | - ROLL SUPPORT |
| 5 | 22E20680 запросить цену → | | RETARD ROLL (REP 8.16) |
| 6 | | | - SPRING PIN |
| 7 | | | - GEAR (16T) |
| 8 | | | - SHAFT |
| 9 | | | - BUSHING |
| 10 | | | - SUPPORT |
| 11 | | | - SCREW (3X8) |
| 12 | | | - UPPER GUIDE |
| 13 | | | - SCREW (3X6) |
| 14 | | | - GROUNDING SPRING |
| 15 | | | - CLUTCH BOSS |
| 16 | 9E57550 запросить цену → | | FEED CLUTCH SPRING |
| 17 | 5E9640 запросить цену → | | CLUTCH SLEEVE |
| 18 | | | - CLUTCH BOSS |
| 19 | | | - GEAR (27T) |
| 20 | | | - GEAR (20T) |
| 21 | | | - TIE WRAP |
| 22 | | | - GROUNDING WIRE |
| 23 | | | - SCREW (3X6) |
| 24 | | | - SCREW (3X6) |
| 25 | | | - SUPPORT PLATE |
| 26 | | | - CLUTCH SLEEVE |
| 27 | | | - CLUTCH SPRING |
| 28 | | | - CLUTCH BOSS |
| 29 | | | - MULTI BYPASS SOLENOID |
| 30 | | | - SOLENOID SPRING |
| 31 | | | - RATCHET ARM |
| 32 | | | - RATCHET ARM |
| 33 | | | - SPRING |
| 34 | | | - SCREW (3X8) |
| 35 | | | - FRAME |
| 36 | | | - SCREW (4X12) |
| 37 | | | - GATE |
| 38 | | | - SUPPORT FRAME |
| 39 | | | - ARM |
| 40 | | | - HINGE |
| 41 | | | - SPRING |
| 42 | 22N948 запросить цену → | | FEEDER ASSEMBLY |
| 5-22 | | | WorkCentre XD SERIES |
| 1 | 50N231 запросить цену → | | TRAY ASSEMBLY |
| 2 | | | - REAR GUIDE |
| 3 | | | - FRONT GUIDE |
| 4 | | | - TRAY COVER |
| 5 | | | - SPRING |
| 6 | | | - GEAR |
| 7 | | | - SCREW (3X6) |
| 8 | | | - TRAY BASE |
| 9 | | | - TRAY EXTENSION |
| 1 | | | - FRONT COVER |
| 2 | | | - SCREW (4X12) |
| 3 | | | - REAR COVER |
| 4 | | | - LEFT TRAY GUIDE |
| 5 | | | - SCREW (4X12) |
| 6 | | | - REAR TIE PLATE |
| 7 | | | - RUBBER FOOT |
| 8 | | | - RIGHT TRAY GUIDE |
| 9 | 809E11980 запросить цену → | | TRANSPORT COVER SPRING |
| 10 | | | - TRANSPORT COVER |
| 11 | 22N970 запросить цену → | | IDLER ROLLER |
| 12 | 9N1072 запросить цену → | | IDLER SPRING |
| 13 | 31N159 запросить цену → | | ARM |
| 14 | 2N1559 запросить цену → | | LOWER SIDE DOOR (USO/XCL) |
| 15 | | | - SCREW (4X8) |
| 16 | | | - SCREW (3X16) |
| 17 | | | - TRAY 2 FEED ASSEMBLY |
| 18 | | | - TRAY 2 HARNESS |
| 19 | | | - 250 CASSETTE ASSEMBLY |
| 5-24 | | | WorkCentre XD SERIES |
| 1 | 22N1029 запросить цену → | | TRAY 2 TRANSPORT ROLLER |
| 2 | | | - BEARING (B-F5-13) |
| 3 | | | - E-RING |
| 4 | | | - DRIVE FRAME |
| 5 | | | - GEAR (20T) |
| 6 | | | - SPRING PIN |
| 7 | | | - CLUTCH BOSS |
| 8 | | | - CLUTCH SPRING |
| 9 | | | - CLUTCH SLEEVE |
| 10 | | | - CLUTCH GEAR (29T) (REP 8.24) |
| 11 | | | - GEAR (40) |
| 12 | | | - ARM |
| 13 | 809E12000 запросить цену → | | SPRING |
| 14 | | | - TRAY 2 HARNESS |
| 15 | 110E5370 запросить цену → | | TRAY 2 PAPER FEED SENSOR |
| 16 | | | - ACTUATOR |
| 17 | | | - GROUND SPRING |
| 18 | 121N411 запросить цену → | | TRAY 2 PAPER FEED SOLENOID |
| 19 | | | - SCREW (3X6) |
| 20 | 7N742 запросить цену → | | CLUTCH PAWL |
| 21 | 809E12010 запросить цену → | | CLUTCH PAWL SPRING |
| 22 | | | - GEAR (18/26T) |
| 23 | 7E29490 запросить цену → | | GEAR (16T) |
| 24 | 110N817 запросить цену → | | TRAY 2 DETECT SWITCH (S5) |
| 25 | | | - TRAY 2 FEED ROLLER (REP 8.25) |
| 26 | | | - TRAY 2 FEED ASSEMBLY |
| 1 | | | - PAPER GUIDE (REP 10.10) |
| 2 | 103N206 запросить цену → | | RESISTOR (1/2 W) |
| 3 | 117N1312 запросить цену → | | GROUND WIRE |
| 4 | 115N284 запросить цену → | | DISCHARGE BRUSH |
| 5 | | | - END COVER |
| 6 | | | - HEAT ROD SPRING (F) |
| 7 | | | - FUSER UPPER FRAME |
| 8 | | | - SCREW (3X6) |
| 9 | 130E7840 запросить цену → | | THERMISTOR (RT1) (REP 10.4) |
| 10 | | | - SCREW (3X10) |
| 11 | 7N695 запросить цену → | | STRIPPER FINGER (REP 10.11) |
| 12 | 130E9190 запросить цену → | | THERMOSTAT (REP 10.9) |
| 13 | 140N5110 запросить цену → | | FUSER JAM SENSOR (Q3) (REP |
| 14 | | | - HEAT ROD SPRING (R) |
| 15 | | | - END COVER (R) |
| 16 | 152N1661 запросить цену → | | HARNESS (230V) |
| 17 | | | - TIE WRAP |
| 18 | 3E10140 запросить цену → | | RETAINING RING |
| 19 | 7E14961 запросить цену → | | DRIVE GEAR (45T) |
| 20 | 13E12780 запросить цену → | | BEARING |
| 21 | 22E23440 запросить цену → | | HEAT ROLL (REP 10.2) |
| 22 | 122N133 запросить цену → | | HEAT ROD (230V) (REP 10.8) |
| 23 | | | - SCREW |
| 24 | 126N70 запросить цену → | | FUSER ASSEMBLY (230V) (REP |
| 5-26 | | | WorkCentre XD SERIES |
| 1 | | | - FUSER ASSEMBLY (P/O PL 6.1 |
| 2 | | | - E-RING |
| 3 | 38N230 запросить цену → | | FUSER GATE (REP 10.12) |
| 4 | 809E43360 запросить цену → | | GATE SPRING (NOT SPARED) |
| 5 | | | - SCREW |
| 6 | | | - FRONT PAPER GUIDE SHEET |
| 7 | | | - FRONT PAPER GUIDE |
| 8 | | | - GROUNDING STRAP |
| 9 | | | - HIGH TEMP CAUTION LABEL |
| 10 | | | - SCREW (3X12) |
| 11 | | | - FUSER LOWER FRAME |
| 12 | | | - PRESSURE ROLL STRIPPER |
| 13 | 31N166 запросить цену → | | PRESSURE ROLL ARM (F) |
| 14 | 22N924 запросить цену → | | PRESSURE ROLL (REP 10.3) |
| 15 | | | - WASHER |
| 16 | 9N1088 запросить цену → | | PRESSURE SPRING |
| 17 | 13E5110 запросить цену → | | PRESSURE ROLL BEARING |
| 18 | 31N167 запросить цену → | | PRESSURE ROLL ARM (R) |
| 19 | | | - HANDLE LABEL |
| 20 | 600K87880 запросить цену → | | FUSER STRIPPER FINGER KIT |
| 1 | 22N927 запросить цену → | | UPPER EXIT ROLLER |
| 2 | 9N966 запросить цену → | | TENSION SPRING |
| 3 | | | - PWB INSULATOR |
| 4 | 140N5111 запросить цену → | | EXIT SENSOR (Q4) (REP 10.7) |
| 5 | 120N275 запросить цену → | | SENSOR ACTUATOR |
| 6 | | | - EXIT GUIDE |
| 7 | | | - TENSION SPRING |
| 8 | 22E22060 запросить цену → | | UPPER ROLLER |
| 9 | | | - GROUNDING SPRING |
| 10 | 152N1630 запросить цену → | | CONTROL CONSOLE RIBBON |
| 11 | | | - FERRITE RETAINER |
| 12 | | | - FERRITE |
| 5-28 | | | WorkCentre XD SERIES |
| 1 | | | - SCREW (3X6) |
| 2 | | | - PWB COVER |
| 3 | | | - CONNECTOR CAP |
| 4 | 140N5114 запросить цену → | | GDI PWB |
| 5 | 140N5113 запросить цену → | | GDI MEMORY PWB (4 MEG) |
| 7 | | | - FUSER HARNESS |
| 8 | | | - MAIN PWB (REF PL7.1B ITEM 1) |
| 9 | | | - PWB MOUNTING BRACKET |
| 10 | | | - SCREW (3X10) |
| 11 | | | - SCREW (3X10) |
| 13 | 140N5115 запросить цену → | | POWER SUPPLY PWB (120V) |
| 14 | | | - SCREW |
| 15 | | | - SCREW (4X12) |
| 16 | | | - STIFFENER BAR |
| 17 | | | - BASE FRAME |
| 18 | | | - RUBBER FOOT |
| 19 | | | - 2ND TRAY CONNECTOR COVER |
| 20 | | | - 2ND TRAY GEAR COVER |
| 21 | 108E3660 запросить цену → | | FUSE (15A)(250V) |
| 22 | 108E5330 запросить цену → | | FUSE (F3) (15A) (250V) |
| 23 | 117E9750 запросить цену → | | POWER CORD (60HZ) |
| 24 | | | - POWER RECEPTACLE (REP 1.4) |
| 25 | 152N1652 запросить цену → | | GDI HARNESS |
| 26 | | | - TIE WRAP (XD155DF) |
| 27 | | | - FERRITE CORE (XD155DF) |
| 28 | 130N911 запросить цену → | | DOCUMENT COVER CLOSED |
| 1 | 140N5473 запросить цену → | | MAIN PWB (W/O [TAG 1]) (XD100, |
| 2 | | | - MOUNTING BRACKET (NOT |
| 3 | | | - BASE FRAME (NOT SPARED) |
| 4 | | | - PWB COVER (NOT SPARED) |
| 5-30 | | | WorkCentre XD SERIES |
| 1 | | | - DRUM CARTRIDGE CONTACT |
| 2 | 152N1625 запросить цену → | | CHARGE COROTRON HARNESS |
| 3 | 152N1622 запросить цену → | | GRID BIAS/MAIN PWB HARNESS |
| 4 | | | - SCREW (3X6) |
| 5 | 9N968 запросить цену → | | CONTACT SPRING |
| 6 | 9N969 запросить цену → | | CONTACT SPRING |
| 7 | 9N967 запросить цену → | | CONTACT SPRING |
| 8 | | | - SCREW (3X8) |
| 1 | | | - DETACK COROTRON |
| 2 | | | - GUIDE |
| 3 | | | - INSULATOR |
| 4 | | | - FRONT GUIDE |
| 5 | | | - SCREW (3X6) |
| 6 | | | - CONTACT COVER (R) |
| 7 | | | - TENSION SPRING |
| 8 | 600K15950 запросить цену → | | TRANSFER COROTRON WIRE |
| 9 | | | - SPRING BRACKET |
| 10 | | | - TRANSFER COROTRON SPRING |
| 11 | | | - BC SPRING |
| 12 | | | - GROUNDING SPRING |
| 13 | | | - CONTACT COVER (F) |
| 14 | | | - COROTRON HOUSING |
| 15 | | | - PLATE |
| 16 | | | - GROUNDING PLATE |
| 17 | 19N415 запросить цену → | | TRANSFER/DETACK COROTRON |
| 5-32 | | | WorkCentre XD SERIES |
| 1 | | | - CL LEAD HARNESS |
| 2 | 152N1632 запросить цену → | | ICU-CCD HARNESS |
| 3 | | | - CENTER FRAME HARNESS |
| 4 | 152N1630 запросить цену → | | OP HARNESS |
| 5 | 152N1633 запросить цену → | | MAIN MOTOR HARNESS |
| 6 | | | - DVS HARNESS |
| 7 | | | - PPD2 INTERFACE HARNESS |
| 8 | 152N1623 запросить цену → | | HL HARNESS (100V) |
| 1 | | | - TOP PACKING CUSHION (L) |
| 2 | | | - TOP PACKING CUSHION (R) |
| 3 | | | - POWER CORD |
| 4 | | | - TIE WRAP |
| 5 | | | - BAG |
| 6 | | | - BAG |
| 7 | 26E39240 запросить цену → | | HALF RATE CARRIAGE |
| 8 | | | - SHIPPING STRAP |
| 9 | | | - BOTTOM PACKING CUSHION |
| 10 | | | - BOX |
| 11 | | | - SHIPPING CUSHION |
| 12 | 120E10520 запросить цену → | | THUMB SCREW |
| 13 | | | - LABEL |
| 14 | | | - DOCUMENT COVER CUSHION |
| 15 | 7N696 запросить цену → | | PRESSURE BLOCK LEVER |
| 16 | 117E18690 запросить цену → | | ALTERNATE |
| 5-34 | | | WorkCentre XD SERIES |
| 1 | | | - TOP PACKING CUSHION (L) |
| 2 | | | - TOP PACKING CUSHION (R) |
| 3 | 117E9750 запросить цену → | | POWER CORD (60HZ) |
| 4 | | | - TIE WRAP |
| 5 | | | - BAG |
| 6 | | | - BAG |
| 7 | | | - SHIPPING CUSHION |
| 8 | | | - SHIPPING CUSHION |
| 9 | | | - BOTTOM PACKING CUSHION |
| 10 | | | - BOX |
| 11 | | | - SHIPPING CUSHION |
| 12 | 120E10520 запросить цену → | | THUMB SCREW |
| 13 | | | - LABEL |
| 14 | | | - DOCUMENT COVER CUSHION |
| 15 | | | - SHIPPING STRAP |
| 16 | 26E39240 запросить цену → | | HALF RATE CARRIAGE |
| 17 | 7N696 запросить цену → | | PRESSURE BLOCK LEVER |
| 18 | 117E19340 запросить цену → | | PRINTER CABLE |
| 19 | | | - PACKING CUSHION |
| 20 | | | - PACKING CUSHION |
| 1 | 6R914 запросить цену → | | TONER CARTRIDGE (USO) |
| 2 | 13R551 запросить цену → | | DRUM CARTRIDGE (USO) |
| 5-36 | | | WorkCentre XD SERIES |
| 1 | | | - DOCUMENT TRAY |
| 2 | | | - FRONT GUIDE |
| 3 | | | - REAR GUIDE |
| 4 | | | - FEED RACK |
| 5 | | | - SCREW (3X8X) |
| 6 | | | - GEAR |
| 7 | | | - SPRING |
| 8 | | | - LOWER COVER |
| 9 | 50N274 запросить цену → | | DUPLEX TRAY (XD155DF) |
| 10 | | | - DSDF COVER (XD155DF) |
| 11 | | | - SDF FEED ASSEMBLY (REF: PL |
| 12 | | | - TIE WRAP |
| 13 | | | - SCREW (4X10) SCREW (4X12) |
| 14 | | | - SCREW (4X10) SCREW (4X14) |
| 15 | | | - SCREW (4X10) SCREW (3X10) |
| 16 | | | - SCREW (3X6) (XD155DF) |
| 17 | 121N419 запросить цену → | | DSDF DEFLECTION GATE |
| 18 | | | - LEVER (XD155DF) |
| 19 | | | - SPRING (XD155DF) |
| 20 | | | - STOPPER (XD155DF) |
| 21 | | | - MYLAR GUIDE |
| 22 | | | - SCREW (3X14) (XD155DF) |
| 23 | | | - MOTOR PAD (XD155DF) |
| 24 | | | - SCREW (3X8) (XD155DF) |
| 25 | | | - LEVER (XD155DF) |
| 26 | | | - BEARING (XD155DF) |
| 27 | | | - E RING (XD155DF) |
| 28 | 50N272 запросить цену → | | DSDF DEFLECTION GATE |
| 29 | 38N273 запросить цену → | | MYLAR GUIDE |
| 30 | 50N257 запросить цену → | | BASE |
| 31 | | | - CUSHION (XD155DF) |
| 32 | 22N999 запросить цену → | | SDF ASSEMBLY (XD103F, |
| 1 | 50N257 запросить цену → | | BASE |
| 2 | 4N192 запросить цену → | | DOCUMENT COVER CUSHION |
| 3 | | | - SCREW (4X10) SCREW (4X14) |
| 4 | | | - HINGE LEFT |
| 5 | 38N254 запросить цену → | | PAD |
| 6 | | | - E-RING (XD155DF) |
| 7 | 22N976 запросить цену → | | SDF EXIT ROLLER |
| 8 | 14N330 запросить цену → | | SPONGE (DUPLEX) |
| 9 | 14N341 запросить цену → | | SPONGE (XD155DF) (DUPLEX) |
| 10 | 6N890 запросить цену → | | EXIT SHAFT |
| 11 | | | - SCREW (3X8) |
| 12 | | | - BEARING (XD155DF) |
| 13 | | | - E-RING (XD155DF) |
| 14 | 15N300 запросить цену → | | PRESSURE PLATE |
| 15 | | | - SCREW (3X10) (XD155DF) |
| 16 | | | - WRAP SPRING (F) (XD155DF) |
| 17 | | | - WRAP SPRING (R) (XD155DF) |
| 18 | | | - SPRING |
| 19 | | | - SHAFT (XD155DF) |
| 20 | 22N973 запросить цену → | | SDF TRANSPORT ROLLER (REP |
| 21 | | | - TRANSPORT SHAFT |
| 22 | | | - SPRING |
| 23 | 38N278 запросить цену → | | PAD (XD155DF)(DUPLEX) |
| 24 | | | - HINGE RIGHT |
| 25 | | | - GROUND STRAP |
| 26 | | | - SCREW (3X14) (XD155DF) |
| 27 | | | - BASE PLATE |
| 28 | | | - GROUND SPRING (XD155DF) |
| 29 | | | - SCREW (3X8) |
| 30 | | | - GROUND SPRING (XD155DF) |
| 31 | | | - DSDF ASSEMBLY (BOTTOM) |
| 5-38 | | | WorkCentre XD SERIES |
| 1 | 2N1563 запросить цену → | | FEED ASSEMBLY TOP COVER |
| 2 | 14N331 запросить цену → | | PAD |
| 3 | | | - PAPER GATE SPRING |
| 4 | 31N161 запросить цену → | | ARM |
| 5 | | | - PAPER GATE |
| 6 | | | - SCREW (3X8) |
| 7 | 140N5199 запросить цену → | | SDF SENSOR PWB (REP 5.16) |
| 8 | 152N1656 запросить цену → | | SDF SENSOR HARNESS |
| 9 | 120N284 запросить цену → | | SET DETECT ACTUATOR |
| 10 | 120N285 запросить цену → | | SENSOR ACTUATOR |
| 11 | 121N410 запросить цену → | | SDF FEED SOLENOID (SOL 1) |
| 12 | | | - SCREW (3X4) SCREW (3X6) |
| 13 | 31N160 запросить цену → | | SOLENOID ARM |
| 14 | 9N1009 запросить цену → | | SPRING |
| 15 | | | - E RING |
| 16 | 7N738 запросить цену → | | CLUTCH GEAR (REP 5.18) |
| 17 | 16N176 запросить цену → | | CLUTCH SLEEVE (REP 5.18) |
| 18 | 9E57580 запросить цену → | | CLUTCH SPRING (REP 5.18) |
| 19 | | | - CAM BOSS (REP 5.18) |
| 20 | 16E9640 запросить цену → | | BUSHING |
| 21 | 6N892 запросить цену → | | CLUTCH SHAFT |
| 22 | 9N1031 запросить цену → | | TENSION SPRING |
| 23 | 20N464 запросить цену → | 20MXE | PULLEY |
| 24 | | | - E RING |
| 25 | 9N1036 запросить цену → | | CLUTCH PAWL SPRING |
| 26 | 7N739 запросить цену → | | CLUTCH PAWL |
| 27 | 22N977 запросить цену → | | RETARD PAD(DUPLEX) (REP |
| 28 | 7E29490 запросить цену → | | GEAR (16T) |
| 29 | | | - SPRING PIN |
| 30 | | | - GEAR (20T) |
| 31 | 5E10560 запросить цену → | | FEED ROLLER (REP 5.19) |
| 32 | 6N891 запросить цену → | | FEED SHAFT |
| 33 | 9N1012 запросить цену → | | SPRING |
| 34 | 31N162 запросить цену → | | ARM |
| 35 | 1N280 запросить цену → | | LOWER COVER |
| 36 | | | - SDF FEED ASSEMBLY (REP 5.22) |
| 1 | | | - DOCUMENT GUIDE |
| 2 | | | - SCREW (3X8) |
| 3 | | | - SCREW |
| 4 | | | - GEAR (27T) |
| 5 | | | - DRIVE ARM |
| 6 | | | - SCREW (3X4) |
| 7 | 127N988 запросить цену → | | SDF DRIVE MOTOR (MOT 1) |
| 8 | | | - GROUND WIRE |
| 9 | | | - SDF HARNESS |
| 10 | | | - TIE WRAP |
| 11 | 9N1071 запросить цену → | | SPRING |
| 12 | | | - DRIVE FRAME |
| 13 | | | - E RING |
| 14 | | | - WASHER |
| 15 | | | - DRIVE BELT (83MXE4.8) |
| 16 | | | - GEAR (48T/15T) |
| 17 | | | - SPRING PIN (2-9) |
| 18 | | | - BEARING |
| 19 | | | - BEARING |
| 20 | 1N281 запросить цену → | | REAR FRAME |
| 21 | | | - RETARD PAD |
| 22 | 15N298 запросить цену → | | PRESSURE PLATE |
| 23 | | | - PRESSURE SPRING |
| 24 | | | - FEED ASSEMBLY LATCH |
| 25 | 38E13480 запросить цену → | | PAD |
| 26 | | | - PULLEY |
| 27 | | | - TRANSPORT DRIVE BELT (REP |
| 28 | | | - PAPER ADVANCE KNOB |
| 29 | | | - EXIT GUIDE SPRING |
| 30 | | | - SDF DOCUMENT TRANSPORT |
| 31 | 130N854 запросить цену → | | SDF DOCUMENT PATH SENSOR |
| 32 | 22N979 запросить цену → | | ROLLER, EXIT |
| 33 | | | - DISCHARGE BRUSH |
| 34 | | | - DOCUMENT GUIDE |
| 35 | 38N261 запросить цену → | | REFLECTOR |
| 36 | 22N978 запросить цену → | | TRANSPORT ROLLER (DUPLEX) |
| 37 | 2N1573 запросить цену → | | SDF FRONT COVER (XD103F, |
| 38 | | | - SDF REAR COVER |
| 5-40 | | | WorkCentre XD SERIES |
| 1 | 38E13480 запросить цену → | | PAD |
| 2 | | | - RETARD PAD |
| 3 | 15N298 запросить цену → | | PRESSURE PLATE |
| 4 | | | - PRESSURE SPRING |
| 5 | | | - UPPER PAPER GUIDE |
| 6 | 22N1001 запросить цену → | | DSDF EXIT ROLLER |
| 7 | | | - DISCHARGE BRUSH |
| 8 | | | - LOWER PAPER GUIDE |
| 9 | | | - SCREW (3X8) |
| 10 | | | - DOCUMENT GUIDE |
| 11 | | | - SDF HARNESS |
| 12 | | | - SCREW (3X6) |
| 13 | 127N988 запросить цену → | | SDF DRIVE MOTOR (MOT1) (REP |
| 14 | | | - PAD |
| 15 | 121N420 запросить цену → | | DSDF EXIT ROLL SOLENOID |
| 16 | | | - TIE WRAP |
| 17 | | | - DRIVE FRAME |
| 18 | | | - SCREW (3X4) |
| 19 | | | - SCREW (3X5) |
| 20 | | | - E-RING |
| 21 | | | - WASHER |
| 22 | | | - DRIVE BELT |
| 23 | | | - GEAR (48T/15T) |
| 24 | | | - SPRING PIN |
| 25 | | | - BEARING |
| 26 | | | - GEAR (30T) |
| 27 | | | - BEARING |
| 28 | 121N418 запросить цену → | | DSDF TRANSPORT ROLL |
| 29 | | | - E RING |
| 30 | | | - BRACKET |
| 31 | | | - OPEN & SHUT LOCK SPRING |
| 32 | | | - SCREW (3X12) |
| 33 | | | - Y 22MXE PULLEY |
| 34 | | | - TRANSPORT DRIVE BELT |
| 35 | | | - PAPER RELEASE KNOB |
| 36 | | | - EXIT GUIDE SPRING |
| 37 | 130N854 запросить цену → | | SDF DOCUMENT PATH SENSOR |
| 38 | | | - SDF DOCUMENT TRANSPORT |
| 39 | | | - DUPLEX GATE |
| 40 | 22N1000 запросить цену → | | DUPLEX TRANSPORT ROLLER |
| 41 | | | - DOCUMENT GUIDE |
| 42 | | | - REFLECTOR |
| 43 | 22N978 запросить цену → | | TRANSPORT ROLLER (REP 5.26) |
| 44 | | | - SLEEVE |
| 45 | | | - TRANSPORT ASSEMBLY (REP |
