| 1 | | | - Left Hand Cover (Not Spared) |
| 2 | | | - Left Hand Upper Chute (Not |
| 3 | | | - Left Hand Chute (Not Spared) |
| 4 | | | - Front Stopper (P/O Item 12) |
| 5 | | | - Pivot Retainer (P/O Item 12) |
| 6 | | | - Latch Handle (P/O Item 13) |
| 7 | | | - Latch (P/O Item 13) |
| 8 | | | - Latch Shaft (P/O Item 13) |
| 9 | | | - Main Baffle (Not Spared) |
| 10 | | | - Rear Stopper (P/O Item 12) |
| 11 | | | - Latch Spring (P/O Item 13) |
| 12 | 604K43860 запросить цену → | | Left Hand Door Kit |
| 13 | 604K43870 запросить цену → | | Left Hand Door Latch Kit |
| 14 | | | - Jam Clear Label (P/O Item 1) |
| 1 | 802K97500 запросить цену → | | Left Hand Cover Assembly (REP |
| 2 | 059E03090 запросить цену → | | Pinch Roll |
| 3 | | | - Pinch Spring (P/O Item 1) |
| 4 | | | - Left Hand Chute (P/O Item 1) |
| 5 | | | - Left Hand Upper Chute (P/O Item |
| 6 | | | - Front Stopper (P/O Item 1) |
| 7 | | | - Duplex Roll 1 (P/O Item 1) |
| 8 | 013E33260 запросить цену → | | Bearing |
| 9 | | | - Pulley (P/O Item 1) |
| 10 | 023E26660 запросить цену → | | Belt |
| 11 | | | - Pivot Retainer (P/O Item 13) |
| 12 | | | - Rear Stopper (P/O Item 13) |
| 13 | 604K43860 запросить цену → | | Left Hand Door Kit |
| 14 | | | - Left Hand Cover (P/O Item 1) |
| 1 | | | - Duplex Main Baffle (P/O PL7.3 Item |
| 2 | | | - Duplex in Chute (P/O PL7.3 Item 1) |
| 3 | 809E76630 запросить цену → | | Idler Spring |
| 4 | | | - Idler Shaft (P/O PL7.3 Item 1) |
| 5 | 059E03650 запросить цену → | | Idler Roll |
| 6 | | | - Latch Spring (P/O Item 14) |
| 7 | | | - Latch Handle (P/O Item 14) |
| 8 | | | - Latch (P/O Item 14) |
| 9 | 013E33260 запросить цену → | | Bearing |
| 10 | | | - Latch Shaft (P/O Item 14) |
| 11 | 807E21180 запросить цену → | | Gear (18T) |
| 12 | 006K86440 запросить цену → | | Duplex Roll |
| 13 | | | - Label (Jam Clear) (Not Spared) |
| 14 | 604K43870 запросить цену → | | Left Hand Door Latch Kit |
| 1 | | | - Bypass Feed Shaft (P/O Item 22) |
| 2 | | | - Bearing (P/O Item 22, Item 27) |
| 3 | | | - Idler Roll (P/O Item 22, Item 28) |
| 4 | | | - Idler Shaft (P/O Item 22, Item 28) |
| 5 | | | - Bypass Idler Spring (P/O Item 22, |
| 6 | | | - Drive Support Bracket (P/O Item |
| 7 | | | - Gear (42/30T) (P/O Item 22, Item |
| 8 | | | - Shaft (P/O Item 22, Item 26) |
| 9 | | | - Idler Arm (P/O Item 22, Item 26) |
| 10 | | | - Gear (49T) (P/O Item 22, Item 26) |
| 11 | | | - Shaft (P/O Item 22, Item 26) |
| 12 | | | - Shaft (P/O Item 22, Item 26) |
| 13 | | | - Sector Gear Spring (P/O Item 22, |
| 14 | | | - Idler Arm Spring (P/O Item 22, Item |
| 15 | 807E17870 запросить цену → | | Gear Pulley |
| 16 | | | - Sector Gear (P/O Item 22, Item 27) |
| 17 | | | - Cam (P/O Item 22, Item 27) |
| 18 | 121E20950 запросить цену → | | Bypass Solenoid |
| 19 | 059K54730 ✓ в наличии | | Bypass Feed Roll (REP 7.5.1) |
| 20 | | | - Feed Roll Cap (P/O Item 22, Item |
| 21 | | | - Bypass Tray (P/O Item 22) |
| 22 | 059K48260 запросить цену → | | Bypass Feeder Assembly |
| 23 | | | - Label (Not Spared) |
| 24 | 604K43820 запросить цену → | | MSI Spring Kit |
| 25 | 022E29860 запросить цену → | | Nudge Roller |
| 26 | 604K45750 запросить цену → | | MSI Assembly No. 2 Repair Kit |
| 27 | 604K45770 ✓ в наличии | | MSI Assembly No. 4 Repair Kit |
| 28 | 604K45780 запросить цену → | | MSI Assembly No. 5 Repair Kit |
| 29 | 604K45790 запросить цену → | | MSI Assembly No. 6 Repair Kit |
| 1 | 050K58051 запросить цену → | | Bypass Tray Assembly |
| 2 | | | - Bearing (P/O Item 15) |
| 3 | | | - Bypass Take Away Roll (P/O Item |
| 4 | | | - Lower Baffle (P/O Item 15) |
| 5 | | | - Nudger Plate (P/O Item 14) |
| 6 | | | - Nudger Pad (P/O Item 13, Item 14) |
| 7 | | | - Nudger Spring (P/O Item 13, PL7.5 |
| 8 | | | - Gear (18T) (P/O Item 15) |
| 9 | | | - Roll (Not Spared) |
| 10 | | | - Retard Spring (P/O PL7.5 Item 24) |
| 11 | 019K08890 запросить цену → | | Retard Pad Assembly |
| 12 | | | - Pre Shingler Bracket (P/O Item 15) |
| 13 | 604K43830 запросить цену → | | Bypass Retard Kit |
| 14 | 604K45740 запросить цену → | | MSI Assembly No. 1 Repair Kit |
| 15 | 604K45760 запросить цену → | | MSI Assembly No. 3 Repair Kit |
| 1 | 110E11320 запросить цену → | | Power Switch |
| 2 | | | - Screw (With Washer) (Not Spared) |
| 3 | | | - Inlet Bracket (Not Spared) |
| 4 | | | - PWB Bracket (Not Spared) |
| 5 | | | - Inlet (Not Spared) |
| 6 | | | - CRUM ID Harness (Not Spared) |
| 7 | | | - Inlet Wire Harness (Not Spared) |
| 8 | | | - Billing Counter Harness (Not |
| 9 | 960K43421 запросить цену → | | AIOC PWB (REP 8.1.1) |
| 10 | 105E17391 запросить цену → | | LVPS (220V) (REP 8.1.2) |
| 11 | | | - Choke Coil (Not Spared) |
| 12 | | | - Power Cord (Not Spared) |
| 13 | 960K28611 запросить цену → | | Exit PWB |
| 1 | 014K83141 запросить цену → | | HV Contact Block |
| 2 | 105E17401 запросить цену → | | HVPS (REP 8.2.1) |
| 3 | 801K25570 запросить цену → | | Left Hand Interlock Switch |
| 4 | | | - Interlock Switch Wire Harness (Not |
| 5 | | | - Core (Not Spared) |
| 6 | | | - Earth Plate (Not Spared) |
| 7 | | | - Front Cover Interlock Switch (Not |
| 8 | | | - Earth Plate (Not Spared) |
| 9 | | | - Harness Block (Not Spared) |
| 10 | | | - Harness Block (Not Spared) |
| 11 | | | - Core Clip (Not Spared) |
| 1 | | | - Support Bracket (Not Spared) |
| 2 | | | - Control Panel Cover (Not Spared) |
| 3 | 962K66150 запросить цену → | | Control Panel Wire Harness |
| 4 | 802K97694 запросить цену → | | Control Panel (ADF, DADF Only) |
| 5 | 896E58070 запросить цену → | | Label (WorkCentre 5020) |
| 1 | | | - Control Panel Panel Case (With |
| 2 | 960K32602 запросить цену → | | UI Platen PWB Assembly (REP |
| 3 | | | - Middle Panel (P/O PL8.3 Item 4) |
| 4 | | | - Label (P/O PL8.3 Item 4) |
| 1 | 848E04480 запросить цену → | | Exit Cover |
| 2 | 848K17300 запросить цену → | | Front Cover Assembly |
| 3 | | | - Front Left Cover (REP 9.1.2) |
| 4 | | | - Output Tray (Not Spared) (REP |
| 5 | | | - Right Top Cover (Not Spared) |
| 6 | | | - Xerox Badge Plate (P/O Item 2) |
| 7 | | | - IIT Support Bracket (Not Spared) |
| 8 | | | - Duct (Not Spared) |
| 9 | 848E04511 запросить цену → | | Front Cover |
| 10 | 801E04660 запросить цену → | | Strap |
| 11 | 105E12210 запросить цену → | | Static Eliminator |
| 1 | 848E04501 запросить цену → | | Rear Cover (Remove Data Plate |
| 2 | 848E04451 запросить цену → | | Right Cover (REP 9.2.2) |
| 3 | 127K51632 запросить цену → | | NOHAD Fan |
| 4 | 053E93650 запросить цену → | | Ozone Filter |
| 5 | | | - Data Plate (Not Spared) (Remove |
| 1 | | | - IIT Right Bracket (Not Spared) |
| 2 | | | - IIT (Not Spared) |
| 3 | | | - Label (Not Spared) |
| 4 | | | - Platen Cover (P/O Item 8) |
| 5 | | | - Platen Cushion (P/O Item 8) |
| 6 | | | - Cap (Not Spared) |
| 7 | 604K47130 запросить цену → | | Error Code Label Kit |
| 8 | 604K46500 запросить цену → | | Platen Cover Kit (REP 10.1.1) |
| 1 | 848K07410 запросить цену → | | IIT Upper Cover (REP 10.2.1) |
| 2 | 604K44330 запросить цену → | | Hinge Kit |
| 3 | | | - Blind Cover (Not Spared) |
| 4 | | | - Plate Spring (P/O Item 2) |
| 1 | 041K95870 запросить цену → | | IIT Carriage (REP 10.3.1) |
| 2 | | | - IIT Under Cover (Not Spared) |
| 3 | 962K59950 запросить цену → | | Flexible Print Cable (REP 10.3.2) |
| 4 | | | - Plate Spring (Not Spared) |
| 5 | 809E79910 запросить цену → | | Cable Spring (Rear) |
| 6 | 809E79920 запросить цену → | | Cable Spring (Front) |
| 7 | | | - Pulley (Not Spared) |
| 1 | 802K71882 запросить цену → | | IIT Upper Cover |
| 2 | 090E02380 запросить цену → | | Small Platen Glass |
| 3 | 090E91720 запросить цену → | | Platen Glass |
| 4 | 815E08650 запросить цену → | | White Referance |
| 5 | 815E42250 запросить цену → | | Sheet (Black and White) |
| 6 | | | - Label (Not Spared) |
| 7 | | | - Label (Not Spared) |
| 1 | | | - Under Cover (P/O PL10.3 Item 2) |
| 2 | 801K30780 запросить цену → | | Front Rail |
| 3 | | | - Rear Frame (P/O PL10.3 Item 2) |
| 4 | 801E05970 запросить цену → | | Rear Rail |
| 5 | | | - Hinge Sleeve (P/O PL10.3 Item 2) |
| 6 | | | - Pulley (P/O PL10.3 Item 2) |
| 7 | | | - Cable Bracket (P/O PL10.3 Item 2) |
| 8 | 110E11551 запросить цену → | | Platen Open Switch |
| 1 | | | - Center Plate (P/O PL10.3 Item 1) |
| 2 | | | - Front Mirror Frame (P/O PL10.3 |
| 3 | | | - Rear Mirror Frame (P/O PL10.3 |
| 4 | | | - Mirror Clip (P/O PL10.3 Item 1) |
| 5 | | | - Mirror 2 Damper (P/O PL10.3 Item |
| 6 | | | - Mirror 3 Damper (P/O PL10.3 Item |
| 7 | | | - Rear Mirror Stopper (P/O PL10.3 |
| 8 | | | - Rear Mirror Stopper (P/O PL10.3 |
| 9 | | | - Mirror Weight (P/O PL10.3 Item 1) |
| 10 | | | - Front Lamp Holder (P/O PL10.3 |
| 11 | | | - Rear Lamp Holder (P/O PL10.3 |
| 12 | | | - Sensor Plate (P/O PL10.3 Item 1) |
| 13 | | | - Reflector (P/O PL10.3 Item 1) |
| 14 | | | - IIT Carriage Cover (P/O PL10.3 |
| 15 | | | - Reflector Cover (P/O PL10.3 Item |
| 16 | 868E12730 запросить цену → | | Sensor Plate Spring |
| 17 | | | - Rail Contact (P/O PL10.3 Item 1) |
| 18 | | | - Mirror Weight (P/O PL10.3 Item 1) |
| 19 | 121K41690 запросить цену → | | Carriage Sensor |
| 20 | 122E92570 ✓ в наличии | | Exposure Lamp (REP 10.6.1) |
| 21 | 127K57140 запросить цену → | | Carriage Motor |
| 22 | | | - Mirror 1 (P/O PL10.3 Item 1) |
| 23 | | | - Mirror 2 (P/O PL10.3 Item 1) |
| 24 | | | - Mirror 3 (P/O PL10.3 Item 1) |
| 1 | | | - Len Assembly (P/O PL10.3 Item 1) |
| 2 | | | - Drum and Carriage Cable (P/O |
| 3 | | | - Pulley (P/O PL10.3 Item 1) |
| 4 | | | - Mirror Clip (P/O PL10.3 Item 1) |
| 5 | | | - Mirror Frame (P/O PL10.3 Item 1) |
| 6 | | | - Side Slider (P/O PL10.3 Item 1) |
| 7 | | | - Rail Contact (P/O PL10.3 Item 1) |
| 8 | | | - Rail Slider (P/O PL10.3 Item 1) |
| 9 | | | - Front Slider (P/O PL10.3 Item 1) |
| 10 | | | - Gear (P/O PL10.3 Item 1) |
| 11 | | | - Gear (P/O PL10.3 Item 1) |
| 12 | | | - Mirror Frame Bracket (P/O PL10.3 |
| 13 | | | - CCD Support (P/O PL10.3 Item 1) |
| 14 | | | - Lock Plate (P/O PL10.3 Item 1) |
| 15 | | | - Inverter PWB Bracket 1 (P/O |
| 16 | | | - Inverter PWB Bracket 2 (Not |
| 17 | | | - Bracket (P/O PL10.3 Item 1) |
| 18 | 140E88751 запросить цену → | | Inverter PWB (REP 10.7.2) |
| 19 | | | - Mirror 4 (P/O PL10.3 Item 1) |
| 20 | | | - Wire Harness (P/O PL10.3 Item 1) |
| 21 | | | - Carriage Cable (Black) (Not |
| 22 | | | - Carriage Cable (Silver) (P/O |
| 23 | | | - Drum (P/O PL10.3 Item 1) |
| 1 | 050K57701 запросить цену → | | Tray 2 (REP 11.1.1) |
| 2 | | | - Single Tray Frame (Not Spared) |
| 3 | 896E41981 запросить цену → | | End Guide Label |
| 4 | 896E42140 запросить цену → | | Install Label |
| 1 | | | - End Guide (P/O PL11.1 Item 1) |
| 2 | | | - Tray (P/O PL11.1 Item 1) |
| 3 | | | - Tray Front Cover (P/O PL11.1 Item |
| 4 | | | - End Guide Spring (P/O PL11.1 Item |
| 5 | | | - Earth Plate (P/O PL11.1 Item 1) |
| 6 | | | - Cover (P/O PL11.1 Item 1) |
| 7 | | | - End Guide Lock (P/O PL11.1 Item |
| 8 | | | - Mini Bottom Plate (P/O PL11.1 Item |
| 9 | | | - Spring (Side) (P/O PL11.1 Item 1) |
| 10 | | | - Spring (Center) (P/O PL11.1 Item 1) |
| 1 | 038K89761 запросить цену → | | Front Side Guide |
| 2 | 038K89821 запросить цену → | | Rear Side Guide |
| 3 | | | - Tapping Screw (P/O PL11.1 Item 1) |
| 4 | | | - Rack (P/O PL11.1 Item 1) |
| 5 | | | - Latch (P/O PL11.1 Item 1) |
| 6 | | | - Pinion (P/O PL11.1 Item 1) |
| 7 | | | - Latch Spring (P/O PL11.1 Item 1) |
| 8 | | | - Rack (P/O PL11.1 Item 1) |
| 1 | 059K48430 запросить цену → | | Tray 2 Feeder Assembly |
| 2 | | | - Feed Chute (P/O Item 1) |
| 3 | 059K48660 запросить цену → | | Tray 2 Feed Roll (REP 11.4.1) |
| 4 | | | - Feed Shaft (P/O Item 1) |
| 5 | 013E90840 запросить цену → | | Bearing |
| 6 | | | - Earth Spring (P/O Item 1) |
| 7 | | | - Core Roll (P/O Item 1) |
| 8 | | | - Holder Seal (P/O Item 1) |
| 9 | 003K15530 запросить цену → | | Front Latch Assembly |
| 10 | | | - Holder Arm (Not Spared) |
| 11 | | | - Spring (Not Spared) |
| 12 | 019K09250 запросить цену → | | Retard Roll Housing |
| 13 | | | - Retard Housing (P/O Item 12) |
| 14 | | | - Retard Holder (P/O Item 12) |
| 15 | | | - Retard Shaft (P/O Item 12) |
| 16 | | | - Friction Clutch (P/O Item 12) |
| 17 | | | - Tray 2 Retard Roll (P/O Item 12) |
| 18 | | | - Retard Plate (P/O Item 12) |
| 19 | | | - Retard Spring (P/O PL11.1 Item 1) |
| 20 | | | - Latch Cover (P/O PL11.1 Item 1) |
| 21 | 003K15540 запросить цену → | | Rear Latch Assembly |
| 22 | | | - Spring (P/O PL11.1 Item 1) |
| 1 | | | - STM Rear Cover (Not Spared) |
| 2 | | | - STM Wire Harness (Not Spared) |
| 3 | | | - Earth Cushion (Not Spared) |
| 4 | | | - Earth Plate (Not Spared) |
| 5 | 110E11580 запросить цену → | | STM Interlock Switch |
| 6 | | | - Sensor Block (Not Spared) |
| 7 | 130E87090 запросить цену → | | STM Feed Sensor (REP 11.5.1) |
| 8 | 120E28091 запросить цену → | | Feed Sensor Actuator |
| 9 | 055K31090 запросить цену → | | STM Baffle Assembly |
| 10 | | | - Roll (P/O Item 9) |
| 11 | | | - Plate Spring (P/O Item 9) |
| 12 | | | - Shaft (P/O Item 9) |
| 13 | | | - Baffle (P/O Item 9) |
| 14 | | | - Eliminator (P/O Item 9) |
| 15 | 960K28562 запросить цену → | | STM PWB (REP 11.5.2) |
| 16 | | | - Guide Spring (Not Spared) |
| 17 | | | - Arm Guide (Not Spared) |
| 18 | | | - Tray Stopper (Not Spared) |
| 19 | | | - Upper Feed Chute (Not Spared) |
| 20 | 809E74030 запросить цену → | | Feed Sensor Spring |
| 21 | | | - Access Cover 2 (Not Spared) |
| 22 | | | - Sensor Wire Harness (Not Spared) |
| 1 | | | - Harness Holder (Not Spared) |
| 2 | 807E18360 запросить цену → | | Gear (Helical 21T) |
| 3 | 059K48440 запросить цену → | | Take Away Roll |
| 4 | 848K02140 запросить цену → | | No Paper Sensor Assembly |
| 5 | 013E32180 запросить цену → | | Bearing (220v) |
| 6 | 807E18410 запросить цену → | | Gear (Helical 20T/36T) |
| 7 | 068K53590 запросить цену → | | STM Feed Clutch (REP 11.6.1) |
| 8 | 127K52180 запросить цену → | | STM Feed Motor (REP 11.6.2) |
| 9 | 807E18380 запросить цену → | | Gear (Helical 51T/15T) |
| 10 | 807E18390 запросить цену → | | Gear (Helical 40T/18T) |
| 11 | 807E18400 запросить цену → | | Gear (Helical 37T) |
| 12 | | | - Tray Rear Stopper (Not Spared) |
| 13 | | | - Earth Plate (Not Spared) |
| 14 | | | - Bearing (Not Spared) |
| 1 | | | - Actuator Support (P/O PL11.6 Item |
| 2 | 120E29630 запросить цену → | | No Paper Sensor Actuator |
| 3 | 130E87090 запросить цену → | | No Paper Sensor (REP 11.7.1) |
| 4 | | | - Sensor Housing (P/O PL11.6 Item |
| 1 | | | - Stand (Not Spared) |
| 2 | 017K93121 запросить цену → | | Caster |
| 3 | 017K93132 запросить цену → | | Caster (With Stopper) |
| 4 | 017E12010 запросить цену → | | Locator Peg |
| 5 | 121E93360 запросить цену → | | Catch Magnet |
| 6 | | | - Front Door (Not Spared) |
| 7 | | | - Stand Hinge (Not Spared) |
| 8 | | | - Door Hinge (Not Spared) |
| 9 | | | - Guide (Not Spared) |
| 10 | 017E98760 запросить цену → | | Support |
| 11 | | | - Screw (Not Spared) |
| 12 | | | - Foot Cover (Not Spared) |
| 13 | | | - Adjuster Foot (Not Spared) |
| 14 | | | - Front Foot (Not Spared) |
| 15 | | | - Foot Bracket (Not Spared) |
| 1 | 022K74860 запросить цену → | | ADF Assembly (with Item 2) (REP |
| 2 | 004E17510 запросить цену → | | Platen Cushion (REP 13.1.2) |
| 3 | | | - Screw (Not Spared) |
| 4 | | | - Push Tie (Not Spared) |
| 1 | 022K75730 запросить цену → | | DADF Scanner Assembly |
| 2 | | | - Rear Cover (Not Spared) |
| 3 | | | - Front Cover (Not Spared) |
| 4 | 050K60800 запросить цену → | | ADF Document Tray Assembly |
| 5 | | | - Front Blind Cover (Not Spared) |
| 6 | | | - Rear Blind Cover (Not Spared) |
| 7 | | | - Support Bracket (Not Spared) |
| 8 | | | - Base Cover Assembly (Not Spared) |
| 1 | 960K42980 запросить цену → | | DADF PWB (REP 13.3.4) |
| 2 | | | - Bracket (Not Spared) |
| 3 | 962K60840 запросить цену → | | ADF Cable |
| 4 | | | - Exit Chute (Not Spared) |
| 5 | | | - Stamp Cover (Not Spared) |
| 6 | | | - Lead In Pinch Roller (Not Spared) |
| 7 | 604K44340 запросить цену → | | Spring Plate Kit (5/Kit) |
| 8 | 059K55600 запросить цену → | | Exit Pinch Roller |
| 9 | 016E93560 запросить цену → | | Bush |
| 10 | | | - Base Cover (Not Spared) |
| 11 | 003K86760 запросить цену → | | Right Counter Balance (REP |
| 12 | 003K13560 запросить цену → | | Left Counter Balance (ADF Only) |
| 13 | | | - Pinch Roll Bracket (Not Spared) |
| 14 | 604K44350 запросить цену → | | Read Out Pinch Roller Kit (5/Kit) |
| 15 | | | - Spring Plate (Read Out) (Not |
| 16 | | | - Interlock Magnet (Not Spared) |
| 17 | | | - Bottom Plate (Not Spared) |
| 18 | | | - ADF Earth Spring (Not Spared) |
| 19 | | | - Film Cover (Not Spared) |
| 20 | | | - Film Cover (Not Spared) |
| 21 | | | - Earth Wire (Not Spared) |
| 22 | 059K55860 запросить цену → | | Pinch Roll Assembly |
| 1 | | | - Upper Feeder Assembly (P/O |
| 2 | | | - Top Cover (Not Spared) |
| 3 | | | - ADF Lower Feeder Assembly (P/O |
| 4 | | | - Pin (P/O PL13.2 Item 1) |
| 5 | | | - Stopper Belt (P/O PL13.2 Item 1) |
| 1 | | | - Document Drive Motor (P/O Item |
| 2 | | | - Motor Plate (P/O Item 24) |
| 3 | | | - Gear (40T-21T) (P/O Item 24) |
| 4 | | | - Bracket (P/O Item 24) |
| 5 | | | - Gear (30T-21T) (P/O Item 24) |
| 6 | | | - Gear (16T-35T) (P/O Item 24) |
| 7 | | | - Bearing (P/O PL13.4 Item 3) |
| 8 | | | - Gear (28T) (P/O PL13.4 Item 3) |
| 9 | | | - Gear (39T-26T) (P/O PL13.4 Item |
| 10 | | | - Bush (P/O PL13.4 Item 3) |
| 11 | | | - Gear (28T-18T) (P/O PL13.4 Item |
| 12 | | | - Gear (22T-16T) (P/O PL13.4 Item |
| 13 | | | - Gear (16T) (P/O PL13.4 Item 3) |
| 14 | | | - Bearing (P/O PL13.4 Item 3) |
| 15 | | | - Gear (17T) (P/O PL13.4 Item 3) |
| 16 | | | - Gear (24T) (P/O PL13.4 Item 3) |
| 17 | | | - Gear (19T) (P/O PL13.4 Item 3) |
| 18 | | | - Gear (51T-30T) (P/O PL13.4 Item |
| 19 | | | - Gear (52T-21T) (P/O PL13.4 Item |
| 20 | | | - Registration Clutch (P/O PL13.4 |
| 21 | | | - Eject Torque Limiter (P/O PL13.4 |
| 22 | | | - Cable Fence (P/O PL13.4 Item 3) |
| 23 | | | - Exit/Invert Clutch (P/O PL13.4 Item |
| 24 | 127K58700 запросить цену → | | Motor Assembly (DADF Only) |
| 25 | | | - Gear Plate (P/O PL13.4 Item 3) |
| 26 | | | - Gear (21T-18T) (P/O Item 24) |
| 1 | | | - Retard Roll Assembly (Not Spared) |
| 2 | | | - Registration Mylar (P/O Item 1) |
| 3 | | | - Retard Mylar (P/O Item 1) |
| 4 | | | - Base Lower Feeder Assembly (Not |
| 5 | | | - Arm Pin (Not Spared) |
| 6 | | | - Shaft (Not Spared) |
| 7 | | | - Paper Guide Plate (Not Spared) |
| 8 | | | - Bearing (Oil Less) (Not Spared) |
| 9 | | | - Gear (15T) (Not Spared) |
| 10 | | | - Roll Assembly (P/O Item 1) |
| 1 | | | - Bottom Chute (Not Spared) |
| 2 | | | - White Sheet (Not Spared) |
| 3 | | | - Bottom Sheet (Not Spared) |
| 4 | | | - Base Frame (Not Spared) |
| 5 | 059K55620 запросить цену → | | Lead In Roll |
| 6 | 059K55630 запросить цену → | | Lead Out Roll |
| 7 | | | - Bearing (Not Spared) |
| 8 | 059K55610 запросить цену → | | Registration Roll |
| 9 | | | - Front Bracket (Not Spared) |
| 10 | | | - Rear Bracket (Not Spared) |
| 11 | | | - ADF Invert Gate (Not Spared) |
| 12 | | | - Seal (Not Spared) |
| 13 | | | - Exit/Invert Sensor (Not Spared) |
| 14 | | | - Sensor Holding Bracket (Not |
| 15 | | | - Registration Sensor (Not Spared) |
| 16 | | | - Registration Sensor Actuator (Not |
| 17 | | | - Registratin Sensor Spring (Not |
| 18 | | | - Exit/Invert Sensor Spring (Not |
| 19 | | | - Exit/Invert Sensor Actuator (Not |
| 20 | | | - Exit/Invert Solenoid Bracket (Not |
| 21 | | | - Solenoid Bracket (Not Spared) |
| 22 | | | - Exit/Invert Solenoid (Not Spared) |
| 1 | | | - Plate (Not Spared) |
| 2 | | | - Gear (18T) (Not Spared) |
| 3 | | | - Bearing (Not Spared) |
| 4 | | | - Exit Roller (Not Spared) |
| 5 | | | - Rear Exit Arm (Not Spared) |
| 6 | 809E56440 запросить цену → | | Spring (Coil) |
| 7 | | | - Front Exit Arm (Not Spared) |
| 8 | | | - Gear (18T) (Not Spared) |
| 9 | | | - Exit Roll Drive Shaft (Not Spared) |
| 10 | | | - Spring Plate (Not Spared) |
| 11 | | | - Spring Plate (Not Spared) |
| 12 | | | - Plate (Not Spared) |
| 13 | | | - Retard Roll Chute (Not Spared) |
| 14 | | | - Retard Roll Drive Shaft (Not |
| 15 | | | - Bush (Not Spared) |
| 16 | | | - Bush (Not Spared) |
| 17 | | | - Spring (Coil) (Not Spared) |
| 18 | 059E04080 запросить цену → | | Retard Roll (REP 13.8.1) |
| 19 | | | - Gear (20T) (Not Spared) |
| 1 | | | - Lock Lever (P/O PL13.4 Item 1) |
| 2 | | | - Spring (P/O PL13.4 Item 1) |
| 3 | | | - Main Shaft (P/O Item 22) |
| 4 | | | - Bearing (P/O Item 22) |
| 5 | | | - Pickup Roll (P/O Item 22) (REP |
| 6 | | | - Pickup Roll Shaft (P/O Item 22) |
| 7 | | | - Housing (P/O Item 22) |
| 8 | | | - Gear (18T-22T) (P/O Item 22) |
| 9 | | | - Feed Roll (P/O Item 22) (REP |
| 10 | | | - Gear (22T) (P/O Item 22) |
| 11 | | | - Plate (P/O PL13.4 Item 1) |
| 12 | | | - Spring Box (P/O PL13.4 Item 1) |
| 13 | | | - Spring (Coil) (P/O PL13.4 Item 1) |
| 14 | | | - Spring Housing (P/O PL13.4 Item |
| 15 | | | - Front Lock Arm (P/O PL13.4 Item |
| 16 | | | - Top Frame (P/O PL13.4 Item 1) |
| 17 | | | - Rear Lock Arm (P/O PL13.4 Item 1) |
| 18 | | | - Sensor Holder (P/O Item 32) |
| 19 | | | - Document Set Sensor Actuator |
| 20 | | | - Document Feeder Width Sensor |
| 21 | | | - Document Feeder Width Sensor, |
| 22 | 059K55640 запросить цену → | | Feeder Assembly |
| 23 | | | - Sensor Holder (P/O Item 37) |
| 24 | | | - Document Feed Sensor (P/O Item |
| 25 | | | - Document Feed Sensor Actuator |
| 26 | | | - Spring (P/O Item 37) |
| 27 | 121K41670 запросить цену → | | Clutch (One Way) |
| 28 | | | - Shaft (P/O PL13.4 Item 1) |
| 29 | 059E99690 запросить цену → | | Registration Pinch Roller |
| 30 | | | - Plate (P/O PL13.4 Item 1) |
| 31 | 110E11570 запросить цену → | | DADF/ADF Top Cover Switch |
| 32 | 121K41650 запросить цену → | | Document Set Sensor Assembly |
| 33 | 121K41600 запросить цену → | | Document Feed Clutch |
| 34 | | | - Gear (20T) (P/O PL13.4 Item 1) |
| 35 | | | - Adjust Plate (P/O PL13.4 Item 1) |
| 36 | | | - Spring (P/O PL13.4 Item 1) |
| 37 | 121K41660 запросить цену → | | Read Sensor Assembly |
| 1 | | | - Earth Plate (P/O PL13.2 Item 4) |
| 2 | | | - Front Side Guide (P/O PL13.2 Item |
| 3 | | | - Rear Side Guide (P/O PL13.2 Item |
| 4 | | | - Width Sensor Actuator (P/O PL13.2 |
| 5 | | | - Eliminator (P/O PL13.2 Item 4) |
| 6 | | | - Pinion Gear (P/O PL13.2 Item 4) |
| 7 | | | - Pinion Spring (P/O PL13.2 Item 4) |
| 8 | | | - Lower Document Tray (P/O PL13.2 |
| 9 | | | - Document Tray Width Sensor 1, |
| 10 | | | - Actuator (P/O PL13.2 Item 4) |
| 11 | | | - Document Tray Length Sensor 1, |
| 12 | | | - Upper Document Tray (P/O PL13.2 |
| 13 | | | - Wire Harness (P/O PL13.2 Item 4) |
