| 1 | | | - Cover |
| 2 | | | - Paper Tray (PL 6.1) |
| 3 | | | - Coupling B Lever |
| 5 | | | - Fuser (PL 5.1) i |
| 6 | | | - Middle Cover (PL 2.2) n |
| 7 | | | - Control Panel (PL 8.1) |
| 8 | | | - Scanner/ADF Assembly |
| 9 | | | - Frame o |
| 10 | 140N63727 запросить цену → | | WIFI PWB |
| 11 | | | - Platen (PL 7.1) |
| 12 | 050N00680 запросить цену → | | Document Pad |
| 13 | 022N02799 запросить цену → | | ADF Module (PL 1.2) |
| 14 | 003N01117 запросить цену → | | ADF Hinge |
| 15 | | | - Connector Cover |
| 16 | 005N01172 запросить цену → | | Surge Protector (South Africa Only) |
| 1 | 022N02801 ✓ в наличии | | ADF Feed Roll Assembly |
| 2 | 127N07864 запросить цену → | | ADF Drive Motor |
| 3 | 022N02800 ✓ в наличии | | ADF Retard Pad |
| 1 | 002N03167 запросить цену → | | Left Cover |
| 2 | 002N03182 запросить цену → | | Right Cover |
| 3 | 002N03172 запросить цену → | | Rear Cover Assembly |
| 4 | 002N03175 запросить цену → | | Front Cover Assembly |
| 5 | | | - Rear Cover |
| 6 | | | - Exit Paper Guide c |
| 7 | | | - Duplex Gate |
| 8 | | | - Spring i |
| 9 | | | - Front Cover Latched Sensor |
| 10 | | | - CRUM PWB |
| 11 | | | - CRUM Contacts |
| 12 | | | - Front Cover o |
| 13 | | | - Manual Cover |
| 14 | | | - Front Harness Cover |
| 15 | | | - CRUM Harness r |
| 1 | 002N03157 запросить цену → | | Left Middle Cover |
| 2 | 002N03158 запросить цену → | | Right Middle Cover |
| 3 | 140N63726 запросить цену → | | FAX PWB |
| 4 | | | - Speaker |
| 5 | | | - FAX Ground |
| 6 | | | - Paper Stacker c |
| 7 | | | - Bin Full Sensor |
| 8 | | | - Spring i |
| 9 | 004N00286 запросить цену → | | Output Support |
| 10 | | | - Antistatic Brush |
| 11 | | | - Exit Cover |
| 12 | | | - Middle Cover Assembly o |
| 1 | 117N01969 запросить цену → | | Flat Cable |
| 2 | 105N02301 запросить цену → | | HVPS |
| 3 | 105N02300 запросить цену → | | LVPS 220V |
| 4 | 121N01247 запросить цену → | | Registration Clutch |
| 5 | 121N01248 ✓ в наличии | | Feed Clutch c |
| 6 | | | - Transfer Roll Holder |
| 7 | | | - Bottom Bar i |
| 8 | | | - Feed Frame |
| 9 | | | - Ground Clip |
| 10 | 022N02803 запросить цену → | | Transfer Roller |
| 11 | | | - Exit Gear o |
| 12 | | | - Feed Gear |
| 13 | | | - Exit Idle Gear |
| 14 | | | - Exit Gear r |
| 15 | 011N00581 запросить цену → | | Paper Feed PWB |
| 16 | | | - Main Exit Frame |
| 17 | | | - Paper Path Frame c |
| 18 | | | - Exit Sensor Frame |
| 19 | | | - LSU Bracket Frame |
| 20 | | | - Left Main Frame |
| 21 | | | - Right Main Frame |
| 22 | 062N00292 запросить цену → | | LSU l |
| 23 | | | - Duplex (PL 4.2) E |
| 1 | | | - M Idle Roller |
| 2 | | | - Washer |
| 3 | | | - Idle Roll Shaft |
| 4 | | | - Spring |
| 5 | | | - Duplex Upper Guide |
| 6 | | | - Duplex Paper Guide c |
| 7 | | | - Duplex Align Bracket |
| 8 | | | - Ground Terminal i |
| 9 | | | - Roller Bushing |
| 10 | | | - Rubber Feed Roller |
| 11 | | | - Feed Shaft |
| 12 | | | - Pulley o |
| 13 | | | - Exit Gear |
| 14 | | | - Flat Rubber Belt |
| 15 | | | - Feed Roller r |
| 16 | | | - Duplex Base Frame |
| 17 | | | - Duplex Latch |
| 18 | 022N02795 запросить цену → | | DUPLEX-set to A4 c |
| 1 | 130N01758 запросить цену → | | Output Tray Full Sensor |
| 2 | | | - Harness |
| 3 | 006N01361 запросить цену → | | Bushing |
| 4 | | | - Exit Frame |
| 5 | 001N00546 ✓ в наличии | | Exit Roller |
| 6 | | | - Decurler Roller c |
| 7 | | | - Exit Shaft |
| 8 | | | - Rubber Exit Dup i |
| 9 | | | - Inner Exit Roller |
| 10 | | | - Outer Exit Roller |
| 11 | | | - Exit Roll Holder |
| 12 | | | - Spring o |
| 13 | | | - Exit Frame Assembly |
| 1 | | | - Earth Transfer Plate |
| 2 | | | - Bushing |
| 3 | | | - Spring |
| 4 | | | - Right Push Brush Plate |
| 5 | | | - Bushing |
| 6 | | | - Left Push Brush Plate c |
| 7 | | | - Spring |
| 8 | | | - Spring i |
| 9 | | | - Feed Bushing |
| 10 | | | - Screw |
| 11 | | | - Exit Shaft Bushing |
| 12 | | | - E-Ring o |
| 13 | 022N02797 запросить цену → | | Registration Roller |
| 14 | | | - Pickup Frame Base |
| 15 | | | - Middle Frame r |
| 16 | | | - Registration Holder |
| 17 | | | - P SAW Plate |
| 18 | 120N00545 запросить цену → | | Feed Sensor Actuator c |
| 19 | 120N00548 запросить цену → | | Registration Sensor Actuator |
| 20 | 130N01759 запросить цену → | | Paper Feed Sensor PWB |
| 21 | | | - Spring |
| 22 | | | - Registration Base Assembly |
| 23 | 050N00681 запросить цену → | | Manual Paper Tray l |
| 24 | | | - Paper Guide Cover E |
| 25 | | | - Registration Idle Shaft |
| 26 | | | - Registration Idle Roller |
| 27 | | | - Manual Left Adjust |
| 28 | | | - Manual Right Adjust |
| 29 | | | - Lower Paper Guide K |
| 30 | | | - Pinion Gear |
| 31 | | | - Roller Cover |
| 32 | | | - Pin |
| 33 | | | - Idle Roller |
| 34 | | | - Spring |
| 35 | | | - Sub-Holder Idle |
| 1 | | | - Duplex Path Sheet |
| 2 | | | - Duplex Guide |
| 3 | 130N01758 запросить цену → | | Sensor |
| 4 | | | - Spring |
| 5 | | | - Paper Tray Empty Sensor |
| 6 | | | - Duplex Guide Lever c |
| 7 | | | - Pick Up Shaft |
| 8 | | | - Pick Up Guide i |
| 9 | 022N02802 запросить цену → | | Paper Drive Roller |
| 10 | | | - Bushing |
| 11 | 130N01760 ✓ в наличии | | Paper Feed Roll Assembly |
| 12 | | | - Feed Roll Holder o |
| 13 | | | - Idle Pick Up Gear |
| 14 | | | - One Way Clutch |
| 15 | | | - Retard Roller r |
| 1 | | | - Left Rear Guide |
| 2 | 127N07865 запросить цену → | | Main Drive Motor |
| 3 | | | - Fuser Drive Out Gear |
| 4 | | | - Knock Up Left Guide |
| 5 | | | - Left Developer Guide Plate |
| 6 | | | - Left Frame c |
| 7 | | | - Shaft Bushing |
| 8 | 007N01802 ✓ в наличии | | Paper Feed Idler Gear i |
| 9 | | | - Idler Gear |
| 10 | | | - Pivot Frame |
| 11 | | | - Idler Gear |
| 12 | | | - Fuser Locking Lever o |
| 13 | | | - Hub Clutch Gear |
| 14 | | | - Feed Gear |
| 15 | | | - Feed Gear 2 r |
| 16 | | | - Cam Coupler |
| 17 | | | - Coupling Lever |
| 18 | 007N01803 запросить цену → | | Main Drive Unit c |
| 19 | | | - Harness Cover |
| 1 | | | - Right Developer Guide Plate |
| 2 | | | - Rear Guide |
| 3 | | | - Lower Guide |
| 4 | | | - Foot |
| 5 | | | - Right Frame |
| 6 | | | - Cable Clamp c |
| 7 | | | - LVPS Cover |
| 8 | | | - Developer Right Guide i |
| 9 | | | - Spring |
| 10 | | | - Ground Clip |
| 1 | | | - Upper Fuser |
| 2 | | | - Fuser Lamp |
| 3 | | | - Lower Fuser |
| 4 | | | - Right Lamp Cap |
| 5 | | | - Fuser Exit Drive |
| 6 | | | - Left Lamp Cap c |
| 7 | | | - Fuser Gear Stopper |
| 8 | | | - Fuser Rear i |
| 9 | | | - Fuser Joint Harness |
| 10 | | | - Thermostat |
| 11 | | | - Thermistor |
| 12 | | | - Fuser Cover o |
| 13 | | | - Exit Roller |
| 14 | | | - Spring |
| 15 | | | - Guide r |
| 16 | | | - Spring |
| 17 | | | - Exit Roller |
| 18 | | | - Exit Shaft c |
| 19 | | | - Exit Gear |
| 20 | | | - Bushing |
| 21 | | | - Rear Guide |
| 22 | | | - Exit Idle Roller |
| 23 | | | - Spring l |
| 24 | | | - Actuator Holder E |
| 25 | | | - Exit Sensor Actuator |
| 26 | 126N00430 запросить цену → | | Fuser Module 110V |
| 1 | | | - Fuser Frame |
| 2 | | | - Heat Roller |
| 3 | | | - Left Bushing |
| 4 | | | - Right Bushing |
| 5 | | | - Gear |
| 6 | | | - Roller c |
| 7 | | | - Spring |
| 8 | | | - Bushing i |
| 9 | | | - Left Jam Lever Link |
| 10 | | | - Antistatic Brush |
| 11 | | | - Jam Lever |
| 12 | | | - Paper Guide Holder o |
| 13 | | | - Lower Fuser Assembly |
| 1 | | | - Lift Plate |
| 2 | | | - Pad |
| 3 | | | - Spring |
| 4 | | | - Pinion Gear |
| 5 | | | - Retard Roll Cover |
| 6 | 050N00683 ✓ в наличии | | Retard Roll Assembly c |
| 7 | | | - Left Paper Guide |
| 8 | | | - Latch Plate i |
| 9 | | | - Spring |
| 10 | | | - Paper Tray Latch |
| 11 | | | - Spring |
| 12 | | | - Right Paper Guide o |
| 13 | | | - Paper Tray Handle |
| 14 | | | - Paper Tray Rear Guide |
| 15 | | | - Paper Tray Frame r |
| 16 | | | - Paper Tray Handle |
| 17 | | | - Paper Indicator |
| 18 | 050N00682 ✓ в наличии | | Paper Tray c |
| 1 | | | - Paper Guide |
| 2 | | | - Upper Scanner Frame |
| 3 | | | - Lower Scanner Frame |
| 4 | | | - Contact Image Sensor (CIS) |
| 5 | | | - Drive Belt |
| 6 | | | - Scanner Drive Motor c |
| 7 | | | - Scanner PWB |
| 8 | | | - Flat Cable i |
| 9 | | | - Sensor |
| 10 | | | - CIS Holder |
| 11 | | | - CIS Guide Shaft |
| 12 | 090N00182 запросить цену → | | Scanner Module o |
| 1 | 140N63722 запросить цену → | | Control Panel PWB |
| 2 | | | - Function Keypad |
| 3 | | | - Number Key Pad |
| 4 | | | - Key Holder Cover |
| 5 | | | - LCD Cover |
| 6 | | | - FAX Key c |
| 7 | 140N63728 запросить цену → | | Control Panel Assembly -3225 DNI |
