| 1 | 002N03166 запросить цену → | | Left Cover (Black) |
| 2 | | | - Top Cover (PL 2.1) |
| 3 | 002N03162 запросить цену → | | Front Cover (Black) |
| 4 | | | - Frame (PL3.1) |
| 5 | 002N03170 запросить цену → | | Rear Cover |
| 6 | | | - Main PWB Insulator |
| 7 | 140N63720 запросить цену → | | Main PWB -3020 BI (DMO-E / |
| 8 | | | - Wireless Cover |
| 9 | 140N63727 запросить цену → | | WNPC (WIFI) PWB |
| 10 | 002N03183 запросить цену → | | Right Cover |
| 11 | 002N03178 запросить цену → | | Paper Support |
| 12 | | | - Front Cover Assembly (Items 3, 11) |
| 1 | | | - Dust Cover |
| 2 | | | - Stacking Guides |
| 3 | | | - Output Support |
| 4 | | | - Inner Output Support |
| 5 | | | - Shaft Holder |
| 6 | | | - Jam Clearance Cover |
| 7 | | | - Trim Strip |
| 8 | | | - Top Cover |
| 9 | | | - WPS Key |
| 10 | 140N63725 запросить цену → | | Control Panel PWB |
| 11 | 002N03159 запросить цену → | | Top Cover Assembly |
| 1 | | | - Paper Tray (PL 3.6) |
| 2 | | | - LSU Frame (PL 3.6) |
| 3 | | | - Main Frame Left (PL 3.4) |
| 4 | | | - Paper Feed Assembly (PL 3.7) |
| 5 | | | - Paper Path Frame (PL 3.3) |
| 6 | 022N02794 запросить цену → | | Transfer Roller |
| 7 | | | - Fuser Module (PL 3.2) |
| 8 | | | - LSU Cover |
| 9 | | | - Main Frame Right (PL 3.5) |
| 10 | | | - HVPS Insulator |
| 11 | | | - HVPS Contact |
| 12 | 105N02303 запросить цену → | | LVPS/HVPS 220V |
| 13 | | | - Input Guide |
| 1 | | | - Exit Cover |
| 2 | | | - Tap Screw |
| 3 | | | - Exit Drive Gear |
| 4 | | | - Exit Gear |
| 5 | | | - Exit Shaft Bushing |
| 6 | | | - Spring |
| 7 | | | - Upper Fuser |
| 8 | | | - Fuser Exit Roller Assembly |
| 9 | | | - Lower Fuser |
| 10 | | | - Fuser Cover |
| 11 | 126N00432 запросить цену → | | Fuser Module Assembly 110V |
| 12 | | | - Exit Shaft |
| 13 | | | - Rubber Rolls |
| 14 | | | - Exit Roller |
| 15 | | | - Holder |
| 16 | | | - Exit Roller |
| 17 | | | - Spring |
| 18 | | | - Bracket |
| 19 | | | - Bushing |
| 20 | | | - Pressure Roll |
| 21 | | | - Bracket |
| 22 | | | - Frame |
| 23 | | | - Fuser Gear Stopper |
| 24 | | | - Jam Lever |
| 25 | | | - Lamp Cover |
| 26 | | | - Fuser Gear |
| 27 | | | - Heat Roll |
| 28 | | | - Guide |
| 29 | | | - Spring |
| 30 | | | - Thermostat |
| 31 | | | - Thermistor |
| 32 | | | - Fuser Cover |
| 33 | | | - Bushing |
| 34 | | | - Fuser Lamp |
| 35 | | | - Jam Lever |
| 36 | | | - Right Lamp Cover |
| 1 | 130N01759 запросить цену → | | Paper Feed Sensor PWB |
| 2 | 120N00546 запросить цену → | | Feed Sensor Actuator |
| 3 | | | - Spring |
| 4 | 120N00547 запросить цену → | | Width Sensor Actuator |
| 5 | | | - Spring |
| 6 | 022N02798 запросить цену → | | Paper Drive Roll |
| 7 | | | - Plate |
| 8 | | | - Ground |
| 9 | | | - Ground Clip |
| 10 | | | - Paper Path Guide |
| 11 | | | - Feed Roll Shaft |
| 12 | 121N01246 запросить цену → | | Feed Clutch |
| 13 | 007N01801 запросить цену → | | Feed Gear |
| 14 | | | - Bushing |
| 15 | | | - Spring |
| 16 | | | - Bushing |
| 17 | 001N00547 ✓ в наличии | | Retard Pad |
| 18 | | | - Path Frame |
| 1 | | | - Left Frame |
| 2 | | | - Feed Drive Gear |
| 3 | | | - RDCN OPC Gear |
| 4 | | | - Out Drive Gear |
| 5 | | | - RDCN Drive Gear |
| 6 | | | - Drive In Gear |
| 7 | | | - Fuser Drive Gear |
| 8 | | | - RDCN Fuser Gear |
| 9 | | | - RDCN A Gear |
| 10 | | | - Drive Motor |
| 11 | 001N00548 запросить цену → | | Left Main Frame Assembly |
| 1 | | | - Right Frame |
| 2 | | | - CRUM Contact |
| 3 | | | - Spring |
| 4 | | | - Ground Clip |
| 5 | | | - Washer |
| 6 | | | - Tap Screw |
| 7 | | | - CRUM Cover |
| 8 | | | - Right Print Cartridge Guide |
| 9 | | | - Right Main Frame (Items 1 - 8) |
| 1 | 001N00549 запросить цену → | | Paper Tray |
| 2 | | | - LSU Frame |
| 3 | | | - Right Guide |
| 4 | | | - Left Guide |
| 5 | | | - Rubber Friction Pad |
| 6 | | | - Bottom Plate |
| 7 | | | - Pinion Gear |
| 8 | | | - Sponge Damper |
| 9 | 062N00293 запросить цену → | | LSU |
| 10 | | | - Motor Cover |
| 11 | | | - LSU Frame |
| 12 | 117N01970 запросить цену → | | LSU Flat Cable |
| 1 | | | - Paper Feed Holder |
| 2 | | | - Feed Roller |
| 3 | | | - Spring |
| 4 | | | - Guide Plate |
| 5 | | | - Latch |
| 6 | | | - Paper Stopper |
| 7 | 130N01757 ✓ в наличии | | Feed Rolls Assembly |
| 8 | | | - Latch |
| 9 | | | - Damper Sponge |
| 10 | | | - Feed Rolls Housing |
| 11 | | | - Feed Rolls Shaft |
| 12 | | | - Shaft Holder |
| 13 | | | - Bushing |
| 14 | | | - Spring |
| 15 | | | - Collar |
| 16 | | | - Joint Gear |
| 17 | | | - Pick Up Clutch |
| 18 | | | - Bushing |
| 19 | | | - Pick Up Roller |
| 20 | | | - Plain Washer |
| 21 | | | - Bushing |
| 22 | | | - Sleeve |
| 23 | | | - Spring |
| 24 | | | - Pick Up Gear |
| 25 | | | - Feed Gear |
| 26 | | | - Drive shaft Roller |
