| 1 | | | Hopping roller shaft 3PP4083-6020P001 |
| 2 | | | Bearing 4PP4083-6022P002 |
| 3 | | | Hopping roller one-way clutch gear 4PB4083-6024P001 |
| 4 | | | Registration roller 3PB4083-6030P001 |
| 5 | | | Bearing (registration) 4PP4083-6031P001 |
| 6 | | | Roller-Transfer B Assy |
| 7 | | | Bearing TR |
| 8 | | | Back-up roller 3PB4083-6064P002 |
| 9 | | | Bias spring 4PP4083-7620P001 |
| 10 | | | Back-up roller bushing 4PP4083-6052P001 |
| 11 | | | Reset lever L 3PP4083-6053P001 |
| 12 | | | Reset lever R 3PP4083-6054P001 |
| 13 | | | Cover open switch arm 3PP4083-6058P001 |
| 14 | | | Stacker cover reset spring 4PP4083-6057P001 |
| 15 | | | Fuser roller idle gear 4PP4083-6080P001 |
| 16 | | | Eject roller idle gear 4PP4083-6081P001 |
| 17 | | | Sensor plate (inlet) 4PP4083-6083P001 |
| 18 | | | Eject sensor lever Assembly 4PA4083-6025G001 |
| 19 | | | Toner sensor (adhesion) 4PP4083-6086G001 |
| 20 | | | Diselectrification bar 4PB4083-6979P001 |
| 21 | 40470101 запросить цену → | | Heat Assy - OP10i |
| 22 | 40470102 запросить цену → | | Heat Assy - OP10i |
| 23 | | | Roller assy - Eject |
| 24 | | | Manual feed guide assy 2PA4128-1149G001 |
| 25 | | | Stacker-Assy |
| 26 | | | LED head unit - 51K |
| 27 | | | Stacker cover damper arm 4PP4083-6191G001 |
| 28 | | | Frame-Base lower |
| 29 | | | Stacker cover damper 4PB4083-6197P001 |
| 30 | 3PP4128-1140P2 запросить цену → | | Stacker Cover Knobs |
| 31 | | | Motor-Pulse (main) |
| 32 | | | Motor-Pulse (regist) |
| 33 | | | Gear-Idle A (Z60/16) |
| 34 | | | Gear-Idle B (Z60/16) |
| 35 | | | Cord-LED Assembly |
| 36 | 40433305 запросить цену → | | Image drum unit (Type 5) |
| 37 | 40433203 запросить цену → | | Toner Cartridge (Type 5) |
| 38 | | | Reduction gear 3PP4083-7617P001 |
| 39 | | | FG plate (O.P.) 4PP4083-7663P001 |
| 40 | | | Hopping roller rubber 4PB4122-1280P001 |
| 41 | | | Diselectritication Film 3PB4083-6089P001 |
| 42 | | | LED Contact 4PP4083-6173P001 |
| 43 | | | Washer C 4PP4120-1210P001 |
| 44 | | | Washer B 4PP4120-1209P001 |
| 45 | | | Spacer-Bearing R |
| 46 | | | Spacer-Bearing L |
| 47 | | | Bias spring A 4PP4083-6065P001 2 Special parts for envelope * |
| 1 | | | Upper cover 1PP4128-1133P001 |
| 2 | | | IC card cover 2PP4128-1155P001 |
| 3 | | | Cover-Lid |
